Function buttons and external sockets

Front panel of the TV set

Volume up/ down
TV/Video
MENU
(input selector
Infrared sensor window
Power switch

Rear panel of the TV set

Video output terminals: VIDEO AUDIO L, R
Video 2 input terminals: VIDEO AUDIO
DVD input terminals: Y, Cb, Cr
If you want to connect the TV set to the other audio/video equipments, please
refer to P23.
Channel selector
Power indicator
Antenna input
L, R
AUDIO L, R
S terminal
Video1 input terminal
Left sound track
Right sound track
