Summary of Contents for YEYIAN Phoenix YCM-APPHO-02
-
Page 2: Product Registration
WELCOME TO YEYIAN A NEW LEVEL IN THE WORLD OF GAMING You’re one of millions upon millions of gamers. You can be socially engaged, sporty, an explorer, a soldier, a builder or a strategist. All of these archetypes require supernatural reflexes, powerful machines, consistency and a strong tolerance to being defeated hundreds upon hundreds of times before the fun kicks in. - Page 3 TE DAMOS LA BIENVENIDA A YEYIAN UN NUEVO ESTÁNDAR EN GAMING DE NIVEL MUNDIAL Ahora formas parte de la comunidad de millones de gamers en el mundo. Puedes ser sociable, deportista, o tener espíritu guerrero, explorador, constructor o estratega. Todas de estas facultades requieren reflejos sobrenaturales, máquinas poderosas, consistencia y una fuerte tolerancia a sufrir cientos de derrotas a manos de otros jugadores antes de que comiences a divertirte.
- Page 4 SPECIFICATIONS ESPECIFICACIONES Model YCM-APPHO-02 Modelo Form Factor Mid Tower Factor de forma Torre Media Overall Dimensions 19.2x8.6x17.3 in Medidas generales 489 x 220 x 440mm Motherboard compatibility Compatibilidad con tarjetas ATX / Micro ATX / ITX madre Max CPU cooler 6.7 in / 170 mm Máximo enfriamiento de CPU Max VGA length...
- Page 5 CHASIS PARTS PIEZAS DE CHASIS Front panel | Panel frontal Metal side panel | Panel lateral metálico Side panel | Panel lateral Removable dust filter | Filtro de polvo extraíble Removable magnetic mesh | Malla magnética extraíble 2.5” SSD tray x 2 | Bandeja para SSD de 2.5” x 2 Hard disk cage | Cajón para disco duro 3.5”...
- Page 6 CONTROL PANEL FUNCTIONS FUNCIONES DEL PANEL DE CONTROL USB Type-C USB3.2 GEN1 (USB3.0) Type-A Microphone | Micrófono Audio USB3.2 GEN1 (USB3.0) Type-A Power Button | Botón de encendido...
- Page 7 HDD/SSD INSTALLATION INSTALACIÓN DE HDD/SSD - Multifunctional hard disk bracket support 3.5” HDD or 2.5” SSD x 1 ( A ) - Multifunctional hard disk bracket support 2.5” SSD x 2 ( C ) - Multifunctional hard disk cage support 3.5” HDD or 2.5” SSD x 1 ( B ) - Soporte multifuncional para disco duro 3.5”...
- Page 8 COOLING SYSTEM INSTALLATION INSTALACIÓN DEL SISTEMA DE REFRIGERACIÓN Front | Frontal Fans | Ventiladores: 120 x 3 or 140 x 3 Radiator | Radiador: Up to 360 mm Top | Superior Fans | Ventiladores: 120 x 3 or 140 x 2 Radiator | Radiador: Up to 360 mm Rear | Posterior Fans | Ventiladores: 120 x 1...
- Page 9 RGB LIGHTING SWITCHING CONEXIÓN DE ILUMINACIÓN RGB Number Connector Descripción Número Conector Connect to motherboard (red) and ADD Header (blue) Conectar a placa base (rojo) y ADD Header (azul) Reset SW Restablecer software At least one PWM fan needs to be connected to the FAN6 position for the computer to detect fan speed data.
- Page 10 FRONT PANEL ROTATION ROTACIÓN DEL PANEL FRONTAL By default, the front panel is installed as shown in the left picture, the light leaks to the right, and the front light effect is not obvious. Turn the front panel upside down, the light leaks to the left, and the front lighting effect will be more obvious.
- Page 11 ARGB DEVICES INSTALLATION DISPOSITIVOS ARGB INSTALACIÓN Press the LED button to cycle through different RGB lighting modes. Pulsa el botón LED para pasar por los distintos modos de iluminación RGB.
