TEST MODE
Start the test mode by keeping the FM key depressed for 5 sec while the set is switched ON, independent of the
actual source, however the diagnostics must not be active.
The hardware and software identification number will be displayed for 1 sec, after that the tuner parameters will be
evaluated acc. to the table below.
AT__FFEF 6 - F (F = good)
hardware number
software number
Or
OT NT
OT
|| |
>
I
field strength
SDR treble cut
frequency
0-F (1 step = 2dB)
kHz / MHz
TUNER
