Bodywork
The outside or the machine can be cleaned with warm
water and a neutral non-abrasive household detergent.
Wipe with clean water and dry after cleaning.
Important : do not use methylated spirit, diluents or
similar products.
Itis advisable, from time to time, to carry out a complete
cycle without a washing load, adding a decalcifying
product.
The detergent dispenser
The detergent dispenser is very easy to remove.
Exert a pressure on the brooches located on each side
ofthe detergent dispenser and pullit up (fig.1 and fig.2).
Clean the detergent dispenser under running water
with a brush or a piece of rag (fig.3). Check that the
siphons located at the back of the detergent dispenser
are not obstructed (fig.4).
Replace the detergent dispenser in the notches until
the hanging (fig.5).
The drain filter
The machine has got a mecanic filter located on the
front part to collect lint and small objects (toothpins,
coins, pins, etc) inadvertently left in the clothes. It is
essential that this filter is cleaned regularly.
Frequency of cleaning depends on the type of articles
washed (cleaning should be more frequent if the arti-
cles have no hem and tend to fray).
™ Open the flapdoor (fig.6)
@ To drain the residual water :
Place below a container not very high up with
straight edges. To complete the draining, turn the
cap of the drain filter until its vertical position and the
residual water will be released (fig.7).
m Toclean the filter :
Turn the filter anticlockwise and get it away (fig.8).
Clean it with current water. Replace the filter and
screw down it clockwise. Then, close the flapdoor.
aeons a7 jensen
15
