Summary of Contents for SWM Hoku 125

  • Page 2: Table Of Contents

    SWM MOTORCYCLES S.R.L. Thanks you for choosing a SWM and would like TABLE OF CONTENTS to remind you that to continually deliver top performance in full safety, your THE SCHEDULED MAINTENANCE PROGRAMME ..........2 SWM motorbike requires regular maintenance by the After Sales Service of TECHNICAL DATA ......................

  • Page 3: The Scheduled Maintenance Programme

    This Quick Manual contains the basic instructions for proper use of the mo- by warranty. SWM MOTORCYCLES S.R.L. may not be held liable for possible torcycle. The complete documentation is contained in the Use and Mainte- injuries suffered by the user of the vehicle as a result of said breakdowns or nance Manual downloadable from the site www.swm-motorcycles.it after...

  • Page 4: Technical Data

    TECHNICAL DATA Spark plug gap................... 0.6-0.7 mm. ENGINE FUEL SYSTEM Type ....................single cylinder, 4 stroke Type..................Electronic injection feed Cooling…………………………………………………………………………… liquid with electric fan PRIMARY DRIVE Water radiators ......................n° 1 Drive pinion gear-Clutch ring gear ............Z 20-Z 67 Bore........................58 mm. Transmission ratio....................3.35 Stroke ........................
  • Page 5 SECONDARY DRIVE Rear…………………………………………………………………………………………………140/70 -17" Transmission sprocket ……………………………………………………………………………Z 13 Cold tyre pressure Rear wheel sprocket ……………………………………………………………………………………Z 45 Front Transmission ratio ………………………………………………………………………………………3.461 Rider only …………………………………………………………………………………………………2.6 bar Transmission chain dimensions. …………………………………………………4/8" x 13/32" Rear CHASSIS Rider only …………………………………………………………………………………………………2.6 bar Type …………trellis perimeter frame made of high-resistance steel tubes DIMENSION, WEIGHT, CAPACITY FRONT SUSPENSION Wheelbase ……………………………………………………………………………………………1360 mm.
  • Page 6 TABLE FOR LUBRICATION, SUPPLIES Engine, gearbox and primary drive lubricating oil MOTUL 10W 40 Brake system fluid MOTUL DOT 4 Grease lubrication MOTUL GREASE 100 Final drive chain lubrication MOTUL CHAIN LUBE Front fork oil MOTUL FORK OIL LIGHT 5W Oil for rear shock absorber MOTUL SHOCK OIL FL Electric contact protection MOTUL EZ LUBE...

  • Page 7: Preliminary Controls

    PRELIMINARY CONTROLS FUEL LEVEL - If the oil needs to be topped up, unscrew the Check the level in the tank, top up as needed ENGINE-TRANSMISSION OIL LEVEL plug (2) and pour the oil through the hole (3) Note until reaching the proper level. Check the oil level when the engine has just been turned off and is still hot.

  • Page 8: Coolant Level

    COOLANT LEVEL Check the coolant level (1) in the radiator when the engine is cold and the motorcycle is in vertical position. The refrigerant must be positioned 10 mm (0,39in) above the elements, check that the level of liquid in the recovery tank (2) is between the minimum “MIN”...

  • Page 9: Right-Hand Side View

    RIGHT-HAND SIDE VIEW 1) Fuel tank cap 2) Fuel tank 3) Instrument panel 4) Headlight 5) Taillight 6) Front turning indicators 7) Rear turning indicators 8) Rear brake disc 9) Rear brake calliper 10) Combined braking control pedal 11) Rear brake pump 12) Engine oil filter 13) Engine oil dipstick 14) Throttle body...

  • Page 10: Left-Hand Side View

    LEFT-HAND SIDE VIEW 1) Side stand 2) Front brake disc 3) Front brake calliper 4) Gear shift pedal 5) Horn 6) Fuse control unit 7) Rider seat 8) Passenger seat 9) Transmission chain 10) Coolant radiator. 11) Plate lighting device 12) Passenger handle 13) Cooling fan 9 - EN...

  • Page 11: Controls And Instruments

    CONTROLS AND INSTRUMENTS 1) Left-hand rear-view mirror 2) Right-hand rear-view mirror 3) Instruments 4) Ignition/steering lock block 5) Clutch control lever 6) Left-hand switch 7) Right-hand switch 8) Throttle twist grip 9) Front brake control lever 10) Front brake fluid reservoir EN-10...

  • Page 12: Instructions For Using The Motorcycle

    INSTRUCTIONS FOR USING THE MO- engine with the gearbox idle, or with the gear en- TORCYCLE gaged and the clutch lever pulled. With the stand lowered, the bike can only be STARTING THE ENGINE started with the gear in neutral. After getting on the motorcycle as described in the relative paragraph, operate as follows to start the engine:...

  • Page 13: R.h. Handlebar Switch

    R.H. HANDLEBAR SWITCH L.H. HANDLEBAR SWITCH 3) Hazard Light The Hazard Light and the Left/right turn signal The left-hand switch features the following con- The right-hand switch features the following con- light comes on when you push on the Warning trols: trols: High beam flasher (self-cancelling).

  • Page 14: Combined Instrument

    -Stop and turn off the engine; -Wait for the engine to cool down and then restart the engine. If the problem occurs again, it is necessary to refer to the nearest SWM’s dealer for a check. 13 - EN...
  • Page 15 -wait for a few minutes and restart the engine. Maintain the engine speed within 11500 rpm If the light turns on again, see the closest SWM dealer to check the ABS system. 5) Unit of measurement TIRE PRESSURE WARNING LIGHT “...

  • Page 16: Function Of Buttons

    PROJECTION INTERFACE SETTINGS Long press DOWNKEY to switch between PROJECTION INTERFACE and MAIN INTERFACE; Display Projection status, Short press enter. Short press up/down key to switch Adroid (default) and IOS. Short press enter return to the Projection interface. BRIGHTNESS SETTINGS Display brightness status ,Short press the “SET”...
  • Page 17 MILEAGE RESET SETTINGS TIRE PRESSURE SETTINGS Display mileage reset status,Short press the “SET” key to enter. Short press Display tire pressure status, Short press the “SET” key to enter. Short press the up/down key to switch between Cancel (default) and Confrim. Short press the up/down key to switch between “Front wheel sensor learning”and ”...
  • Page 18 In the event of a fault, the relevant “ABS” error code is indicated on the dis- play (1), the relevant “ECU” error code is indicated on the display (2); Find the nearest SWM dealer to check the fault. 17 - EN...
  • Page 19 ABS MALFUNCTION LIST Malfunction Possible Causes Possible Impact Recommended Measures C1101 ECU Voltage supply: high voltage Poor connect of battery terminal. ABS alarms and not working. Clean the terminal. C1102 ECU Voltage supply: low voltage Poor connect of battery terminal. ABS alarms and not working.
  • Page 20 Malfunction Possible Causes Possible Impact Recommended Measures ECU error (hardware, Micro-controller er- C1604 ABS Internal damange ABS internal damange and not working. Replace ABS ror) C2308 Valve fault, inlet valve front ABS Internal damange ABS internal damange and not working. Replace ABS C2312 Valve fault, outlet valve front...
  • Page 21 APPENDIX: DTC LIST System or component Error code Error description Driver behavior Coolant/Oil Temperature Sensor Circuit High Voltage P0118 Stop the engine and check whether the cylinder temperature or Open Coolant/Oil Sensor sensor is connected effectively. If the error still persist ask for P0117 Coolant/Oil Temperature Sensor Circuit Low Voltage assistance.
  • Page 22 System or component Error code Error description Driver behavior P0232 FPR Coil Circuit High Voltage Check if the fuel pump relay is connected effectively. If the Fuel Pump Relay (FPR) error still persist ask for assistance. P0231 FPR Coil Circuit Low Voltage or Open P014D Slow response of front oxygen sensor from thin to thick Check if the front oxygen sensor is connected effectively.
  • Page 23 System or component Error code Error description Driver behavior Check if there's history error. Reset. If the error still persist ask P0650 MIL Circuit Malfunction for assistance. P2195 Front oxygen sensor PE too thin Front Oxygen Sensor Front oxygen sensor too thick when fuel cutoff for de- P2196 celeration P0132...
  • Page 24 System or component Error code Error description Driver behavior P1693 Tachometer Circuit Low Voltage Check if the crankshaft position sensor is connected effec- Tachometer tively. If the error still persist ask for assistance. P1694 Tachometer Circuit High Voltage Check if the circuit is connected effectively. Reset. If the error Idle Control System P0505 Idle Speed Control Error...

  • Page 25: Stopping The Motorcycle And The Engine

    STOPPING THE MOTORCYCLE AND THE ENGINE ENGINE EMERGENCY STOP -Fully close the throttle twist grip (1) to decelerate -Flick the red switch (7) to stop the engine and then flick it back to position the motorcycle. When the bike is off, place it on its side stand. -Apply both front (2) and rear (3) brakes while downshifting (for sharp deceleration, operate in a decided manner on the brake lever and pedal).

  • Page 26: Side Stand

    SIDE STAND STEERING LOCK The motorcycle comes with a steering lock A side stand (1) is supplied with every motorcycle. located on the ignition switch (1). Lock the WARNING steering as follows: -Turn the handlebar to the left The stand is designed to support the WEIGHT of -Insert key (2) in the ignition switch (1) set to the MOTORCYCLE ONLY.

  • Page 27: Fuses

    FUSES Two fuses (10) are present under the rider seat, F1) 25A fuse Motor power fuse Fuse malfunction could cause problems for the that protect the battery charge generator and F2) 15A fuse motorcycle. the charge socket under the passenger seat, re- ABS fuse To access the fuse box, remove the passenger spectively.

  • Page 28: Warranty

    Warranty and service booklet 27 - EN...
  • Page 29 Your new bike is guaranteed free from original ient to you, we invite you to ask at any other SWM the motorcycle. defects in compliance with EC Rule 99/44.
  • Page 30 For all vehicles: the warranty on the BATTERY, Consumables and parts subject to wear: SADDLE and PLASTIC PARTS is limited to 6 and presented to the official SWM dealer The warranty does not cover wear and normal months. every time the vehicle is brought in for service ...
  • Page 31 …………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… EN-30...
  • Page 32 The motorcycle has been made ready for delivery by performing all of the checks and pre-delivery actions livery of the motorcycle as described above, as provided for by SWM MOTORCYCLES S.R.L., and fitted out with all the possible optional parts as re- equipped and fully compliant with my expec- quested by the Buyer.
  • Page 33 …………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… EN-32...
  • Page 34 Mail in a closed envelope to: SWM MOTORCYCLES S.R.L. Servizio Assistenza Tecnica, Via Nino Bixio, 8 – 21024 Biandronno (VA) -Italy SWM MOTORCYCLES S.R.L. and its official sales organization state that the personal details of the Copy for SWM MOTORCYCLES S.R.L.
  • Page 35 ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………………… EN-34...
  • Page 36 Space reserved for storing fiscal documents proving that scheduled maintenance services have been carried out. SERVICE DATE Km/Ml Customer’s signature Dealer’s stamp SERVICE DATE Km/Ml Customer’s signature Dealer’s st amp SERVICE DATE Km/Ml Customer’s signature Dealer’s stamp SERVICE DATE Km/Ml Customer’s signature Dealer’s st amp SERVICE...
  • Page 37 SWM Motorcycles, assembled in CN SWM Motorcycles srl, Via Nino Bixio 8, 21024 Biandronno (VA), Italy ph. +390332769911, fax +390332769958, info@swm-motorcycles.it, www.swm-motorcycles.it EN-36...
