OWNER'S MANUAL
DRYER
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
DL*7000* / DL*710** / DL*715**
www.lg.com
MFL72045805
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
Rev.00_030524

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL 7000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LG DL 7000 Series

Summary of Contents for LG DL 7000 Series

  • Page 1 Scan to see the online manual. OWNER'S MANUAL DRYER Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH DL*7000* / DL*710** / DL*715** www.lg.com MFL72045805 Copyright © 2024 LG Electronics Inc. All Rights Reserved. Rev.00_030524...

  • Page 2: Table Of Contents

    24 OPERATION Before Use Loading the Dryer Control Panel Dry Cycles Cycle Modifiers Options and Extra Functions 35 SMART FUNCTIONS LG ThinQ Application Smart Diagnosis Function 36 MAINTENANCE Regular Cleaning 38 TROUBLESHOOTING FAQs Before Calling for Service 43 LIMITED WARRANTY...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety for a Dryer WARNING Fire Hazard Failure to follow safety warnings exactly could result in serious injury, death or property damage. Do not install a booster fan in the exhaust duct. •...

  • Page 4: Warning Statements

    IMPORTANT SAFETY INSTRUCTIONS WARNING Risk of Fire Install the clothes dryer according to the manufacturer’s instructions and local codes. Clothes dryer installation must be performed by a qualified installer. • Do not install a clothes dryer with flexible plastic venting materials. If •...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS • The appliance must be installed and electrically grounded by qualified service personnel in accordance with local codes. • Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance. • When moving or installing the appliance in a different location, call qualified service personnel for installation and service.
  • Page 6 • Do not grasp the power cord or touch the appliance controls with wet hands. • Do not modify or extend the power cord. • If the appliance has been submerged, contact an LG Electronics customer information center for instructions before resuming use.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS • Do not put living animals such as pets inside the appliance. • Do not put any part of your body, such as your hands or feet, or metal objects under the appliance. • Do not let your hand get pinched when opening or closing the dryer door. •...

  • Page 8: Product Overview

    PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Front View Control panel Lint filters Leveling feet Reversible door Rear View...
  • Page 9 PRODUCT OVERVIEW Water inlet hose connection (for steam models) Exhaust duct oulet Product Specifications Model DL*7000* / DL*710** / DL*715** Please refer to the rating label for detailed Electrical Requirements information. Dimensions (Width X Depth X Height) 27'' X 29 1/2'' X 44 1/2'' (68.6 cm X 75.0 cm X 113.0 cm) Maximum Depth with Door Open 50 1/4'' (127.5 cm) Gas : 118.6 lb (53.8 kg)

  • Page 10: Installation

    10 INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this dryer or transporting it to another location. Choose the proper location. Level the appliance. Vent the appliance. Connect the Gas / Electric dryer. Plug in the power cord.

  • Page 11: Choosing The Proper Location

    INSTALLATION Choosing the Proper • For garage installation, you will need to place the appliance at least 18 inches (45.7 cm) above the Location floor. The standard pedestal height is 15 inches (38 cm). You will need 18 inches (45.7 cm) from the garage floor to the bottom of the appliance.
  • Page 12 12 INSTALLATION Dimensions and Clearances The following clearances are recommended for the appliance. • Additional clearances should be considered for ease of installation and servicing. • Additional clearances should be considered on all sides of the dryer to reduce noise transfer. Installation Spacing for Recessed Area or Closet Installation Description Dimension/Clearance...
  • Page 13 INSTALLATION NOTE • There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer of vibration from one appliance to another. If there is enough vibration, it could cause appliances to make noise or come into contact, causing paint damage and further increasing noise. •...

  • Page 14: Leveling The Appliance

    14 INSTALLATION Leveling the Appliance NOTE • If you are installing the appliance on the optional WARNING pedestal, you must use the leveling feet on the • Use long-sleeved gloves and safety glasses. pedestal to level the appliance. The appliance leveling feet should be fully retracted.

  • Page 15: Installing The Vent Kit

    INSTALLATION cover caps on the opposite sides from which they were removed. While supporting the door, remove the 2 With the hinges and cover caps in the new screws on the door hinge, two from each locations, remount the inner door frame onto hinge.
  • Page 16 NOTE • An adapter kit, part number 383EEL9001B, may be purchased from your LG retailer. This kit contains duct components necessary to change the appliance vent location. • Right-side venting is not available on gas models.

  • Page 17: Stacking The Appliance

    INSTALLATION Stacking the Appliance Tools Required • Phillips screwdriver Stacking Kit Installation Place the appliance on top of the washer, fitting the dryer feet into the side brackets as WARNING illustrated. Avoid finger injuries; do not allow • The weight of the appliance and the height of fingers to be pinched between the washer installation make this stacking procedure too and the appliance.
  • Page 18 18 INSTALLATION • Do not allow ductwork to rest on or contact NOTE sharp objects. • Deduct 6 ft. (1.8 m) for each additional elbow. Do • If connecting to existing ductwork, make sure it not use more than four 90° elbows. is suitable and clean before installing the dryer.

  • Page 19: Connecting Gas Dryers

    INSTALLATION Incorrect Venting • DO NOT use an open flame to inspect for gas leaks. Use a noncorrosive leak detection fluid. • Gas pressure must not exceed 10.5-inch (26.7 cm) water column for NG, or 13-inch (33.1 cm) water column for LP. •...

  • Page 20: Connecting Electric Dryers

    20 INSTALLATION for the type of gas being used (natural gas or propane gas). • Use only a new stainless steel flexible connector and a new AGA-certified connector. • A gas shutoff valve must be installed within 6 ft. (1.8 m) of the dryer. •...

  • Page 21: Final Installation Check

    INSTALLATION Test Dryer Heating • The appliance has its own terminal block that must be connected to a separate 230 VAC, 60- Hertz, single-phase circuit, fused at 30 amperes. Gas Models (The circuit must be fused on both sides of the Close the dryer door and press the Power button line.) ELECTRICAL SERVICE FOR THE APPLIANCE to turn the dryer on.
  • Page 22 22 INSTALLATION buildup and free of restrictions allows clothes to Check the display for results. dry faster and reduces energy use. • During the test cycle, monitor the Flow Sense display on the control panel. If the NOTE Flow Sense LED has not turned on when •...
  • Page 23 INSTALLATION Check for blockages and lint buildup. Error Possible Cause & Solution Code Temperature snesor failure. • Turn off the appliance and call for service. Humidity sensor failure. • Turn off the appliance and call for service. Electric dryer power cord is not connected correctly, or house power Make sure the ductwork is not crushed or supply is incorrect.

  • Page 24: Operation

    24 OPERATION OPERATION Before Use WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Operation Overview Adjust Settings Default settings for the selected cycle can now be changed, if desired, using the cycle Clean the Lint Filter modifier and option buttons.

  • Page 25: Loading The Dryer

    OPERATION Woven and Loopknit Materials fingers. Push the lint filter firmly back into place. See Regular Cleaning for more information. • Some woven and loopknit materials may shrink, depending on quality. Permanent Press and Synthetics • Do not overload your dryer. Take out permanent press items as soon as the dryer stops to reduce wrinkles.
  • Page 26 26 OPERATION Tumble Dry Label Directions Do not tumble dry Do not dry (used with do not wash) Heat Setting Label Directions High Medium No Heat / Air...

  • Page 27: Control Panel

    OPERATION Control Panel Control Panel Features Power Button • Press the button to turn the appliance on. Press again to turn the appliance off. NOTE • Pressing the Power button during a cycle will cancel that cycle, and any load settings will be lost. Cycle Selector Knob •...
  • Page 28 28 OPERATION Time and Status Display Clean Filter Reminder • The Clean Filter indicator lights up at the beginning of the cycle to remind you to check the lint filter. It turns off when the Start/Pause button is pressed. Cycle Status Indicators •...

  • Page 29: Dry Cycles

    Sensor Dry Cycles Sensor dry cycles utilize LG's unique dual sensor system to detect and compare the moisture level in clothes and in the air and adjust the drying time as needed to ensure superior results. The appliance automatically sets the dryness level and temperature at the recommended setting for each cycle.
  • Page 30 30 OPERATION Cycle Perm. Press Dry Level Default: Normal Available: All Temperature Default: Medium Available: Medium Manual Dry Cycles Use Manual Dry cycles to select a specific amount of drying time. When a Manual Dry cycle is selected, the actual time remaining in your cycle appears on the display. You can change the actual time in the cycle by pressing the More Time or Less Time buttons.
  • Page 31 OPERATION † This option helps to reduce the energy use by drying clothes at lower temperatures than the normal mode. When this option is set, the drying time will increase.

  • Page 32: Cycle Modifiers

    32 OPERATION Cycle Modifiers About Modifier Buttons Each cycle has default settings that are selected automatically. Customize these settings using the cycle modifier buttons. Repeatedly press the button for the desired modifier until the indicator light for the desired setting is lit. Not every option is available with every cycle.

  • Page 33: Options And Extra Functions

    OPERATION Options and Extra Functions • When the option is turned on, only the Power button works after the drying cycle ends. Your dryer includes several additional cycle • To select the option after starting a cycle, pause options to customize cycles to meet your individual the cycle, set the option, and press Start/Pause.
  • Page 34 34 OPERATION • When the function is deactivated, a chime will sound and the remaining time for the current cycle will reappear on the display.

  • Page 35: Smart Functions

    Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application.

  • Page 36: Maintenance

    36 MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They will damage the finish. Regular Cleaning Cleaning the Lint Filter Always clean the lint from the filter after every Cleaning the Exterior cycle.
  • Page 37 MAINTENANCE If the lint filter has become very dirty or clogged with fabric softener, wash the lint filter in warm, soapy water and allow it to dry thoroughly before reinstalling. NOTE • NEVER operate the appliance without the lint filter in place.

  • Page 38: Troubleshooting

    Scan this QR code to quickly access the video search page on the offical LG website. On the lg.com/us home page, click on the Support menu tab to bring up the menu selections. Select Video Tutorials. Type Dryer in the search box on the new page and click the Search button.

  • Page 39: Before Calling For Service

    TROUBLESHOOTING Before Calling for Service The dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the dryer does not function properly or does not function at all, check the following before you call for service.
  • Page 40 40 TROUBLESHOOTING Problem Possible Cause & Solution The appliance will House fuse is blown, circuit breaker has tripped, or power outage has occurred. not turn on. • Reset circuit breaker or replace fuse. Do not increase fuse capacity. If the problem is a circuit overload, have it corrected by a qualified electrician.
  • Page 41 TROUBLESHOOTING Problem Possible Cause & Solution Drying time is not Heat settings, load size, or dampness of clothing is not consistent. consistent. • The drying time for a load will vary depending on the size of the load, the type of fabrics, the wetness of the clothes and the condition of the lint filter.
  • Page 42 42 TROUBLESHOOTING Problem Possible Cause & Solution Excess static in Fabric softener is not used or is used incorrectly. clothes after drying. • Use a fabric softener or the Reduce Static option, if available, to reduce static electricity. Be sure to follow the manufacturer’s instructions. Clothes dried too long (overdried).

  • Page 43: Limited Warranty

    ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Dryer ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. ("LGECI") will, at its option, repair, replace or pro rate the Product upon receipt of proof of the original retail purchase.
  • Page 44 (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
  • Page 45 If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein.
  • Page 46 Except as otherwise provided for, LG waives any rights it may have to seek attorneys’ fees and expenses from you if LG prevails in the arbitration.
  • Page 47 Memo...
  • Page 48 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: U.S.A. 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...
