Feather Rollator 11X - Carbon Fiber

Owners Manual

Product: Feather Rollator 11X - Carbon Fiber

Sku: F-CF-11XR

Brand: Feather

Congratulations on buying the World's Lightest Rollator!!

At only 11Lbs, the Feather Rollator is one of the lightest products in the world. Giving freedom of mobility has never been

easier! With brand-new materials, the Feather Rollator sets a new standard for lightweight accessibility devices. Anyone

can lift this rollator into a car, truck, or SUV. The rollator features a comfort seat and storage bag.

Feather Carbon Fiber Rollator Owners Manual

JUL2024_01

Need help?

Do you have a question about the 11X and is the answer not in the manual?

Questions and answers

Summary of Contents for Feather 11X

Page 1 Congratulations on buying the World’s Lightest Rollator!! At only 11Lbs, the Feather Rollator is one of the lightest products in the world. Giving freedom of mobility has never been easier! With brand-new materials, the Feather Rollator sets a new standard for lightweight accessibility devices. Anyone can lift this rollator into a car, truck, or SUV.
Page 2 Precautions For Safe Use…………………………………………….…….…….…….……..…….…….…….……….……..………3 Performance And Structure…………………………………………….…….……...…….…….…….…….…….…….……….…13 Technical Features………………………………………….…….…….…….…….…….……….………...……..……….…….……..15 Assembling, Folding, And Adjusting…………………………………………….…….……..……….……..……….…….……..16 Use And Operation…………………………………………….…….…….…….…….…….……….…….……..……….…….……..20 Fault Analysis And Troubleshooting…………………………………………….…….…….……….……..……….…….……..24 Safety Protection Device And Accident Handling…………………………….……………….……..……….…….……..24 Maintenance And Repair…………………………………………….…….…….…….…….…………………..……….…….……..24 Transportation And Storage…………………………………………….…….…….…….…….…….……….……….…….……..27 General Guidance…………………………………………….…….…….…….…….…….…….…….……………..…….…….……..27 Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 3 It is important that you read through this manual entirely before operating your chair. You will ﬁnd instructions and recommendations for easy operation of the Feather Rollator. Read and follow all instructions, warnings, and notes in this manual before attempting to operate your rollator for the ﬁrst time.
Page 4 We hope rollator can bring greater convenience to your life. Disclaimer JYD Imports, HOVER, 1800 Wheelchair, or Feather Mobility, its afﬁliates, and partners, cannot be held responsible for personal injury or property damage that results from the unsafe or improper operation or maintenance of the Feather product and/or other JYD Imports, HOVER, or 1800 Wheelchair products purchased.
Page 5 This rollator is designed for persons with restricted mobility with a maximum body weight of 300 lbs for use as a walking or standing aid and rehabilitation training as well. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 6 2. Handle 3. Brake lever 4. Handle adjustment mechanism 5. Handle adjustment push-button 6. Storage bag 7. Folding mechanism 8. Main frame 9. Front wheel 10. Rear wheel 11. Curb climber 12. Seat mesh Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 7 17) This rollator has the certain ability of groove obstacle, at this time you should reduce the speed and travel slowly. 18) Indications for use: The Feather rollator is an indoor and outdoor transportation device with the intended use to provide convenience for disabled and elderly individuals with limited mobility.
Page 8 Do not store other objects on the rollator. This will prevent damage caused by long-term weight on the materials and frame. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 9 You must adhere to the following safety guidelines if you decide to do so: Keep ashtrays a safe distance from the seat cushions. Always make sure cigarettes are completely extinguished before disposal. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 10 Wheel Material Solid, Polyurethane, No Fill Brakes Manual, lock in place Minimum Turning Diameter 60” Distance Between Handles 17.5” to 20” Width of Handle Sleeve 2” Seat Material Oxford Mesh Frame Material Carbon Fiber Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 11 2) Press and hold the handle adjustment push-button until the numerical marking appears and a “click” is heard to adjust the handle height. (Different numerical markings represent different heights, adjust as needed) Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 12 3) Close the handle adjustment mechanism as shown in the image. 4) Unfolding the Rollator – Lift the security hook up. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 13 5) Pull the handles outwards. 6) Push downwards on the outer rails of the seat until you hear a signiﬁcant click from the locking mechanism. Right now, the seat crossbar is fully locked. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 14 7) Check whether the upper tube of the crossbar on the seat is completely pushed into the groove of the seat ﬁxing frame. Conﬁrm the hook on the locking mechanism is completely clamped into the locking shaft. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 15 Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 16 Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 17 Press the security hook down until it snaps into the cross bar from the seat. Attaching and Removing the Back Strap Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 18 Attaching and Removing the Storage Bag Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 19 WARNING! Make sure that both brake levers are in parking mode before sitting down. Also make sure both brake levers are in parking mode or squeeze the brake levers for clicking the brake on if standing and taking some rests are needed. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 20 To put the Rollator Brakes in BRAKE MODE – Squeeze the brake lever with four ﬁngers to slow down the rollator or turn the quick brake on. Release the brake handle to start the walking mode. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 21 Then step on the curb and continue moving once the rollator is stable. WARNING! Be aware that the stability of the rollator changes when it is reclined. Be cautious and try to bypass rather than climb high obstacles. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 22 Seat Height Adjustment To accommodate end users with different heights, three options are available to adjust the seat to ﬁt. The adjustment steps: Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 23 Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 24 It is important that you pay close attention to all warnings in this section. If you fail to do so, you may fall, tip over or lose control resulting in severe injury to yourself or others. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 25 WARNING! Do not modify your rollator in any way not authorized by the manufacturer. Do not use accessories if they have not been tested or approved for your speciﬁc rollator. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 26 WARNING! Do not carry baggage weighing more than 10 lbs (4.5 kg) on the back of the rollator. Carrying or tying baggage in excess of 10 lbs. (4.5 kg) on the back of the rollator may affect the center of gravity, resulting in a tip or a fall. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 27 ● Never sit in this Feather product while in a moving vehicle. In an accident or sudden stop you may be forced out of the rollator from the impact.
Page 28 WARNING! You should not travel up or down a potentially hazardous incline (ie areas covered with snow, ice, cut grass, or wet leaves) WARNING! Never travel down an incline backward. Doing so may cause the rollator to tip over. Always exercise extreme caution when negotiating an incline. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 29 Never reach down between your knees or over the back of the seat as these movements can change your center of gravity and the weight distribution of the rollator. This may cause your rollator to tip over. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 30 ■ Check the caster forks for damage or ﬂuttering which indicates that they may need to be adjusted or have the bearings replaced. Keep your rollator clean and free of foreign material, such as mud, dirt, hair, food, and drink. Feather Carbon Fiber Rollator Owners Manual JUL2024_01...
Page 31 Replacing any hardware or rollator components with non-approved parts may result in faulty operation of your Feather product and may cause harm to the end user. Using non-ofﬁcial brand parts or making unauthorized changes to a Feather product will void the product warranty.
Page 32 See the complete line at FeatherMobility.com — the World’s Lightest Wheelchairs and Scooters https:/ /feathermobility.com Feather Carbon Fiber Rollator Owners Manual JUL2024_01...

This manual is also suitable for:

F-cf-11xr
