OWNER'S MANUAL
Electric Dethatcher 13A
Copyright All Rights Reserved.
Model DT71613S
This product has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the owner's manual before
using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING,
ASSEMBLY, PARTS, SERVICE QUESTIONS? GO TO
SCOTTS.AMERICANLAWNMOWER.COM, OR CALL 1-800-618-7474
BETWEEN 8:00AM-5:00PM EST, MONDAY-FRIDAY FOR ASSISTANCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Scotts DT71613S
Summary of Contents for Scotts DT71613S
- Page 1 WARNING: To reduce the risk of injury, the user must read and understand the owner’s manual before using this product. Thank you for your purchase. DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING, ASSEMBLY, PARTS, SERVICE QUESTIONS? GO TO SCOTTS.AMERICANLAWNMOWER.COM, OR CALL 1-800-618-7474 BETWEEN 8:00AM-5:00PM EST, MONDAY-FRIDAY FOR ASSISTANCE. SAVE THIS MANUAL FOR FUTURE REFERENCE...
- Page 2 DANGER! Risk of electric shock. Do not use in rain or electrical storms. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. Model DT71613S...
-
Page 3: Replacement Parts
If in doubt, use the next heavier children’s reach. gage. The smaller the gage number, the heavier the cord. Model DT71613S... - Page 4 LIGHTING - Only operate your appliance in daylight www.P65Warnings.ca.gov. or good artificial light. Do not operate the dethatcher on a slope that is too steep for safe operation. When on slopes, slow down and make sure you have good footing. Model DT71613S...
-
Page 5: Product Specifications
PRODUCT SPECIFICATIONS Model: DT71613S Power supply voltage: 120 V-60 Hz Working width: 16-IN No Load Speed: 3200 RPM Working depth: -10 mm ~ 10 mm Power Consumption: 13 Amp Grass Catcher Capacity: 1.1 Bushel Description Description Upper handle Motor housing... -
Page 6: Packing List
Lift up the rear deck cover (5) and attach the grass HANDLES ASSEMBLY catcher (6) with hooks (7) onto the slots on motor housing. (Fig. 5) • Lift up the lower handle by turning the lock knob (A) clockwise to tighten. ( Fig.2) Fig.5 Fig.2 Model DT71613S... - Page 7 Do not work on extremely steep slopes. Empty the grass box when it is full in order to prevent the blade from becoming clogged and the motor from being overload. Model DT71613S...
-
Page 8: Maintenance
Fold the upper handle down, During extended periods of storage, ensure that the and store the dethatcher in a suitable place. dethatcher is protected against corrosion and rust. Model DT71613S... -
Page 9: Troubleshooting
Empty grass catcher bag and remove blockage CALL US FIRST !! Call us first with questions about operating or maintaining your dethatcher at 1-800-618-7474 between 8:00 a.m. – 5:00 p.m. Eastern Standard Time, or get assistance on scotts.americanlawnmower.com. Model DT71613S... -
Page 10: Parts And Service
PARTS AND SERVICE For parts or service, please call 1-800-618-7474 or visit us online at scotts.americanlawnmower.com. Be sure to provide all relevant information when you call or visit. REPAIR PARTS (KITS/ ITEMS) The model/ serial number of this tool is found on a plate or label attached to the housing. Please record the serial number in the space provided below. - Page 11 ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ Model DT71613S...
-
Page 12: Warranty Policy
2 Year limited warranty on all Scotts corded power tools from date of purchase when used for personal, household, or family use. The Great States Corp. (GSC)warrants to the original owner that this Scotts product and service part is free from defects in materials and workmanship and agrees to repair or replace any defective product or part for the warranty period as stated above. - Page 13 NO DEVUELVA ESTE PRODUCTO A LA TIENDA. ¿TIENE PREGUNTAS SOBRE EL FUNCIONAMIENTO, EL MONTAJE, LAS PIEZAS Y EL MANTENIMIENTO? IR A SCOTTS.AMERICANLAWNMOWER.COM, O LLAME AL 1-800-618-7474 ENTRE LAS 8:00 AM Y LAS 5:00 PM HORA DEL ESTE DE LOS ESTADOS UNIDOS.
- Page 14 No usar en la lluvia. No usar durante tormentas eléctricas. Los productos eléctricos no se deben desechar junto con los residuos domésticos. Recicle donde haya centros para tal fin. Consulte a la autoridad local o al distribuidor minorista para obtener asesoramiento sobre reciclado. Modelo DT71613S...
-
Page 15: Advertencias De Seguridad Importantes
STW-A, STOW-A, SJW-A, SJOW-A , SJTW-A. o SJTOW-A. firme y buen equilibrio en todo momento. PONGA ATENCIÓN. Observe lo que está haciendo. Use el sentido común. No opere el rotocultivador si está cansado o bajo la influencia de drogas o medicamentos. Modelo DT71613S... - Page 16 ADVERTENCIA: Cáncer y Daño Reproductivo - ADVERTENCIA: Reemplace el cable dañado www.P65Warnings.ca.gov. inmediatamente. Modelo DT71613S...
-
Page 17: Especificaciones Del Producto
ESPECIFICACIONES DEL PRODUCTO Modelo: DT71613S Voltaje del suministro eléctrico: 120V-60HZ Ancho de trabajo: 40 cm (16 pulg.) Sin velocidad de carga: 3200 RPM Profundidad máx. de trabajo: -10 mm ~ 10 mm Consumo de potencia: 13 amperios Capacidad del colector de hierba: 1.1 bushel... -
Page 18: Montaje
(6) con ganchos (7) en las ranuras de la carcasa del motor. (Fig. 5) ASAMBLEA DE MANIJAS • Levante la manija inferior girando la perilla de bloqueo (A) en sentido horario para apretar. ( Figura 2) Fig.5 Fig.2 Modelo DT71613S... - Page 19 No trabaje en pendientes extremadamente empinadas. Vacíe la caja de césped cuando esté llena para evitar que la cuchilla se obstruya y el motor se sobrecargue. Modelo DT71613S...
-
Page 20: Mantenimiento
Dobla la manija superior hacia abajo y contra la corrosión y el óxido. almacena el dethatcher en un lugar adecuado. Modelo DT71613S... -
Page 21: Detección Y Solución De Problemas
Vacíe la bolsa recolectora de hierba y elimine el bloqueo. ¡LLÁMENOS PRIMERO! Si tiene preguntas sobre el funcionamiento o el mantenimiento de su producto al 1.800.618.7474, de 8:00 a 17:00, hora estándar del este, , o obtener asistencia en scotts.americanlawnmower.com. Modelo DT71613S... -
Page 22: Piezas Y Servicio
PIEZAS Y SERVICIO Para solicitar repuestos o servicio técnico, llame al 1-800-618-7474 o visite nuestra página web scotts.americanlawnmower.com. Asegúrese de proporcionar toda la información relevante cuando nos llame o visite. REPUESTOS (KITS / ARTÍCULOS) El número de modelo/ de serie de esta herramienta se encuentra en una placa o etiqueta adjunta a la caja. - Page 23 ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ Modelo DT71613S...
- Page 24 Política de garantía de Scotts • Garantíalimitada de 2 años para todas las herramientaseléctricas con cable Scotts a partir de la fecha de compracuando se utilizan para uso personal, doméstico o familiar. The Great States Corp. (GSC) garantiza al propietario original que esteproducto y pieza de servicio Scotts estánlibres de defectos de materiales y mano de obra y aceptareparar o reemplazarcualquierproducto o piezadefectuosadurante el período de garantíaindicadoanteriormente.
-
Page 25: Manuel De L'utilisateur
CONCERNANT LE FONCTIONNEMENT, L’ASSEMBLAGE, LES PIÈCES OU LA RÉPARATION DU PRODUIT? ALLER À SCOTTS.AMERICANLAWNMOWER.COM OU COMPOSEZ LE 1-800-618-7474 E 8 h 00 à 17 h 00, HEURE DE L’EST, POUR TOUTE ASSISTANCE. CONSERVEZ CE MANUEL POUR POUVOIR LE CONSULTER ULTÉRIEUREMENT... - Page 26 N’utilisez pas cette machine sous la pluie. N’utilisez pas cette machine pendant les orages électriques. Les équipements électriques usagés ne doivent pas être éliminés avec les ordures ménagères. Recyclez l’appareil lorsque des installations à cet effet existent. Pour obtenir des conseils de recyclage, renseignez-vous auprès des autorités locales ou de votre vendeur. Modèle DT71613S...
-
Page 27: Pièces De Remplacement
STOW-A, SJW-A, SJOW-A. , SJTW-A. ou SJTOW-A. RESTER VIGILANT – Regardez ce que vous faites. Faites preuve de bon sens. N’utilisez pas le cultivateur/la griffe si vous êtes fatigué ou sous l’influence de médicaments, de drogues ou d’alcool. Modèle DT71613S... - Page 28 AVERTISSEMENT : Cancer ET Troubles de l'appareil AVERTISSEMENT: Remplacez immédiatement le cordon reproducteur - www.P65Warnings.ca.gov. endommagé. ÉCLAIRAGE – N'utilisez votre appareil qu'à la lumière du jour ou sous une bonne lumière artificielle. Modèle DT71613S...
-
Page 29: Spécifications Du Produit
SPÉCIFICATIONS DU PRODUIT Modèle : DT71613S Tension d’alimentation : 120 V – 60 HZ Largeur du sillon : 40 cm (16 po) Vitesse des peignes: 3200 tr/m Profondeur maximale de labour : -10 mm ~ 10 mm Consommation : 13 A Capacité... - Page 30 (6) avec crochets (7) sur les fentes du carter du une condition dangereuse entraînant des blessures moteur. (Fig.5) graves possibles. ASSEMBLAGE DES POIGNÉES • Soulevez la poignée inférieure en tournant le bouton de verrouillage (A) dans le sens des aiguilles d'une montre pour serrer. (Fig.2) Fig.5 Fig.2 Modèle DT71613S...
- Page 31 à la pente dans une position solide et sûre. Ne travaillez pas sur des pentes extrêmement raides. Videz le bac à herbe lorsqu'il est plein afin d'éviter que la lame ne se bouche et que le moteur ne soit surchargé. Modèle DT71613S...
-
Page 32: Entretien
Rabattez la poignée la corrosion et la rouille. supérieure vers le bas et rangez la déchaumeuse dans un endroit approprié. Modèle DT71613S... -
Page 33: Dépannage
Videz le sac récupérateur d'herbe et retirez le blocage APPELEZ-NOUS D’ABORD!! Appelez-nous d'abord pour toute question concernant le fonctionnement ou la maintenance de votre tronçonneuse au 1-800-618-7474 entre 8h00 et 17h00, heure normale de l'Est, ou obtenir de l'aide sur scotts.americanlawnmower.com. Modèle DT71613S... - Page 34 PIÈCES ET SERVICE RÉPARATION Pour les pièces ou la réparation, veuillez appeler le 1-800-618-7474 ou visitez-nous en ligne au scotts.americanlawnmower.com. Veillez fournir toute l'information pertinente lorsque vous nous appelez ou nous rendez visite. PIÈCES DE RECHANGE (KITS/ ARTICLES) Le numéro de modèle/ de série de cet outil se trouve sur une plaque ou une étiquette fixée au bâti.
- Page 35 ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ Modèle DT71613S...
-
Page 36: Garantie
Politique de garantie Scotts • Garantie limitée de 2 ans sur tous les motoculteurs filaires Scotts à compter de la date d’achat lorsqu’ils sont utilisés à des fins personnelles, domestiques ou familiales. The Great States Corp. (GSC) garantit au propriétaire original que ce produit et cette pièce de rechange Scotts sont exempts de défauts de matériaux et de fabrication et accepte de réparer ou remplacer tout produit ou pièce défectueux pendant la période de garantie comme...
