2.1 Short description
• HG44e: Semi-hermetic four-cylinder reciprocating compressor with suction-gas cooled drive motor.
• HG56e: Semi-hermetic six-cylinder reciprocating compressor with suction-gas cooled drive motor.
• Preferred application range: normal refrigerating and air-conditioning.
Transport eyelet
Valve plate
Oil pump
D
GB
F
E
Suction
shut-off valve
Dimension and connection values can be found in Chapter 10
6 | AQ451925859810en-000301
Fig. 1
Fig. 2
Terminal box
Name plate
Oil sight glass
HG44e
Discharge
shut-off valve
Motor section
HG56e
© Danfoss | Climate Solutions | 2024.07
Cylinder
cover
Drive
section
