Summary of Contents for neverdark MOSSWOOD
- Page 1 Neverdark MOSSWOOD Smart fireplace TECHNICAL DOCUMENTATION...
-
Page 3: Table Of Contents
CONTENT FIREPLACE CONFIGURATION Standard configuration FIREPLACE INTERFACE DIMENSIONS INSTALLATION INSTALLATION Fireplace installation Distance requirements CONNECTION FEATURES TECHNICAL Technical data DATA Warnings... - Page 4 ATTENTION! This document, together with the User Manual, is part of the device and is delivered together with the fireplace (hereinafter collectively referred to as "Instructions"). If one or both of these documents did not come with your fireplace, please contact the manufacturer before installing and/or using the fireplace.
-
Page 5: Configuration
CONFIGURATION Standard configuration Remote Smart fireplace control 1 pc 1 pc Woodbox Fuel hose decorative natural firewood 1 set 1 pc Power cable: Euro Plug - WAGO Micro USB cable (length: fireplace (service only) length + 0.1m) 1 pc 1 set Fuel drain hose + hex key Documentation... -
Page 6: Fireplace Interface
FIREPLACE INTERFACE Woodbox Tray for decorative elements Burner Decorative natural Air ventilation firewood grids Glass border Control panel cover Fuel drain hose (service only) Power cable 220V 05 | fireplace interface... -
Page 7: Dimensions | 06
DIMENSIONS Standard range Length, Depth, Height, Weight, Model Code (fireplace) Mosswood (woodbox) dimensions | 06... -
Page 8: 07 | Installation
INSTALLATION Fireplace installation You can position the woodbox in relation to the fireplace in the way that you you like to match the interior. Standard configurations are shown below. You can also order an additional woodbox for a family for a more convenient location. Additional woodbox 07 | installation... - Page 9 1. To put the woodbox on top of the fireplace, insert the hex key into the four holes on the top of the fireplace and push them out on 10 mm. 2. Place the woodbox on the guides. 3. To put a fireplace on top of the woodbox, you need to repeat steps 1 and 2, but on top of the woodbox.
-
Page 10: Distance Requirements
Distance requirements ATTENTION! For correct operation of the smart fireplace, it must be installed 100% horizontally according to the level! WARNING! Min 1000 mm to flammable objects from any opened side of the fireplace. Min 500 mm to flammable objects from any closed side of the fireplace. -
Page 11: Connection | 10
CONNECTION ATTENTION! 220V cable connection must be carried out by a qualified electrician. Plug 220V (option 1) Cable 220V 3x2.5mm (option 2) connection | 10... -
Page 12: Features
FEATURES Technical data Fireplace model Parameters Chalet-I (In) Tank volume, l System volume, l Consumption, I/h 0,4 | 1 (min | max) Average consumption, I/h Burning time, h 3,0 | 7,5 (min | max) Room size*, m 27 | 68 (min | recommended) Max power consumption, kW 0,90... -
Page 13: Warnings
Manual were not followed, the manufacturer is not responsible for any damage to objects above or next to the fireplace resulting from exposure to high temperatures. For the safe use of the Neverdark ATTENTION! smart fireplace, follow the rules: Keep away from children;... - Page 16 NEVERDARK LLC 11 Kopernika St. Kyiv, Ukraine neverdark.one...
