Giant Loop PANNIER MOUNTS PNMT-19 Mounting And Installation Instructions

RECOMMENDED OPTIONAL ACCESSORIES
Tillamook Dry Bag
Waterproof double-ended
duffel anchors between
Panniers.
Possibles Pouch
Straps to front or back
of Panniers, creating
3.5-liter waterproof,
quickly accessible
external pockets.
GL PANNIER MOUNTS
MOUNTING INSTRUCTIONS AND WARRANTY INFORMATION
NOTE: Failure to follow recommended mounting and installation instructions voids warranty. Manufacturer is not liable for any damage, injury or death that results from improper
use and installation of products. By installing these products, user accepts all liabilities, terms and conditions outlined in the Liability & Warranty statement included here.
TERMS OF USE, LIMITED LIFETIME WARRANTY AND LIABILITY WAIVER
Giant Loop LLC, an Oregon company, having its principal place of business in Bend, OR
("Giant Loop") offers its motorcycle bag (the "Product") with the terms, conditions and
notices as follows:
TERMS OF USE
This Product is offered to you conditioned upon your acceptance without modification of
the terms, conditions, and notices contained herein. Installation and/or use of this product
implies acceptance of all such terms, conditions, and notices. If you do not agree to these
terms, do not buy the Product. If you have already bought the Product and do not agree to
these terms, return this Product promptly, including the packaging and all written materials,
to Giant Loop.
LIMITATION OF LIABILITY AND LIMITED LIFETIME WARRANTY DISCLAIMER
Giant Loop offers a money-back guarantee provided the Product is returned, in unused
condition with original receipt, within 30 days of purchase. Giant Loop reserves the right to
subtract a 15% re-stocking fee from the refund amount. Standard shipping fees will apply to
exchanged items and are paid by the customer. If you receive damaged or defective goods
or items that you did not order, the items must remain unopened and unused so we can
credit you in full, including return shipping if it is a result of our error, mishandled shipping or
manufacturer's defect.
Giant Loop provides to the original purchaser a limited lifetime warranty against defects in
materials or craftsmanship if purchased directly from a Giant Loop authorized dealer. This
warranty covers defective materials and craftsmanship only, and does not include damage due
to normal wear and tear or misuse. Failure to comply with the included instructions for this
Product will void the limited lifetime warranty. If defects in the materials or craftsmanship of
the Product exist, notify Giant Loop immediately of the defect. Giant Loop will provide for repair
or replacement of the Product, after Giant Loop has determined, in our sole discretion, that a
defect is present. Proof of purchase is required to utilize the limited warranty provisions.
0619
™
If you experience any problems with the Product within the warranty period please return the
Product or contact us for prompt repair or replacement at our discretion:
ride@giantloopmoto.com, 458-206-9113.
Excepting the warranties stated in the preceding paragraph, Giant Loop hereby disclaims
all other warranties and conditions with regard to the Product including all implied
warranties and conditions of merchantability and fitness for a particular purpose. There are
no warranties which extend beyond the description on the face hereof. Giant Loop does
not warrant against damages or defects arising out of use or installation of the Product.
Installation instructions are provided for your convenience. Giant Loop is not responsible
for any damages arising out of the installation, improper or otherwise, of the Product. No
warranty of any kind, expressed or implied, is made regarding the safety of this Product.
To the extent allowed by law, Giant Loop shall not be held liable for any direct, indirect, punitive,
incidental, special or consequential damages arising out of, or connected with, the use or
misuse of this Product. Buyer assumes all risks and liability arising from use of this Product.
ENTIRE AGREEMENT
This document states the entire obligation of Giant Loop with respect to the Product. If any
part of this agreement is determined to be void, invalid, unenforceable or illegal, including,
but not limited to the warranty disclaimers and liability limitations set forth above, then the
remainder of the agreement shall remain in full force and effect.
APPLICABLE LAW
This agreement is governed by the laws of Oregon, USA. You hereby consent to the
exclusive jurisdiction and venue of the courts of Oregon, USA, in all disputes arising
out of or relating to the use of this product.
MOUNTING AND INSTALLATION INSTRUCTIONS
84" QuickLoop
Security Cable
Add peace of mind by
locking Panniers to
parked motorcycle.
NOTE: Failure to follow recommended mounting and installation instructions voids warranty. Manufacturer is not liable for any damage, injury or death that results from improper
use and installation of products. By installing these products, user accepts all liabilities, terms and conditions outlined in the Liability & Warranty statement included here.
Pronghorn Straps
Multi-use stretch
polyurethane straps
anchor gear to GL
Pannier Mounts, tail
racks and more.
PRE-FITTING
GL Pannier Mounts can be configured to fit an array of popular luggage rack designs by moving the location of the bottom mount hooks to one of four positions.
Hooks can then be adjusted vertically for a snug, secure fit.
To determine bottom mount
hook placements, test fit the GL
Pannier Mounts starting with the
pre-installed positions. Hooks
can be moved to any of the four
positions, and each of the two
bottom hooks can be installed
in the best location to avoid
obstructions or contact with the
motorcycle's exhaust system.
With hooks loosely fitted into
their optimal positions, click the
quick-connect clasp onto rack.
Slide hooks in slots to create a
solid, rattle-free fit.
Position Position
The locking clasp
1 2
can be attached
to three different
positions
It is critical to ensure that no part of the Mounts makes contact with the bike's exhaust system.
Position thumbscrew so it's accessible to finger tighten, and so it's not touching any part of the exhaust.
GL PANNIER MOUNTS
KEY LOCK FOR EXTRA SECURITY
BMW R1200GS
GL Pannier Mounts feature a locking
mechanism to secure them to your
For the BMW R1200GS Adventure's OEM luggage rack, install
luggage rack. Simply snap the quick-
the optional GSA Adapter blocks on the exhaust side GL Pannier
connect clasp onto the luggage rack,
Mount, between the mount plate and the quick-connect clasp.
insert key and turn to lock.
HOOK POSITIONS
Position
VERTICAL ADJUSTMENT
3
GL Part No. PNMT-19
™
ADAPTER GL Part No. PNMT-GSA
Webbing
slots
Position Position Position Position
1 2 3 4
Use one of the four slot positions to locate mount hooks
where they clear obstructions and hot exhaust. Adjust hooks
vertically in slots for a tight fit when the quick-connect clasp
is attached to the rack.
Insert thumbscrew in either bottom hook - whichever
position avoids contact with exhaust or other obstructions.
Loosen thumbscrew when connecting/disconnecting
mounts and tighten to prevent hooks from sliding.
After hooks are properly
positioned and adjusted,
mark their locations and
reinstall with blue medium-
strength thread lock on
bolts to prevent them from
vibrating loose.
