Technical data
What this chapter contains
This chapter contains the technical details of the assistant control panel.
Connectors
The control panel has the following connectors:
Connector
RJ-45 female connector
Type B mini USB connector
Pin assignment of RJ-45 connector:
Purpose
Used for connecting the control panel to the drive.
• The maximum permitted cable length is 100 meters (328 ft.)
• On a panel bus, the combined maximum length of the panel
bus cables is 100 meters (328 ft.).
• The panel bus can have a maximum of 32 nodes.
Used for connecting panel to a PC. It is intended for temporary
service use (USB 2.0, MTP protocol). The maximum cable length
is 3 meters (9.8 ft.).
Technical data 89
11
