5.9. TIMER SETTINGS
The timer has two ways of operation:
TO TURN OFF
(when power on)
TO TURN ON
(when power off)
CANCEL TIMER
5.10. AUTOMATIC DEFROST
At low room temperatures, frost may build up at the evaporator during operation. The unit will automatically start defrosting and the
POWER LED will start blinking. The defrost control sequence is as follows:
5.10.1. When the unit operates in the cooling operation, drying operation, the ambient temperature sensor senses the evaporator coil
temperature is below -1°C, after the compressor will stop operating for 10 minutes or the coil temperature up to 7
cool operating mode.
5.10.2. When the unit operates in the heating operation, drying operation, once the coil temperature sensor senses the temperature of the
evaporator is below 40
compressor operation for 20minutes, the unit start defrosting for 5 minutes and the power indicator blinking.
5.11. OVERLOAD PROTECTION
In the event of a power loss, there is a 3 minute delay before the appliance will restart.
FIG.7
5.12. DRAINAGE
The unit has two methods of drainage. These are manual (fig.7, point 5.13) or continuous (fig.8, point 5.14).
5.13. MANUAL DRAINAGE (FIG.7)
5.12.1. Turn off the appliance once the water is full.
5.12.2. Unplug the appliance from the power supply.
NOTE: If moving the machine, do it carefully so you do not spill water in the pan at the bottom of the body.
5.12.3. Place a container underneath the waste water outlet.
5.12.4. Remove the sealing plug and gently title the appliance backwards to aid drainage. Water will flow into the container.
5.12.5. Replace the sealing plug.
NOTE: It is recommended to restart the appliance afterwards to reduce condensation running onto the floor.
DO NOT submerge the end of hose into water; otherwise it can cause "Air Lock" in the hose.
8
NOTE: TO AVOID WATER SPILLAGE. As the negative pressure of condensate drain pan is large, tilt the drain hose downward toward
the floor. It is appropriate that the degree of inclination should exceed 20 degrees. Straighten the hose to avoid a trap existing in the hose.
5.14. CONTINUOUS DRAINAGE (FIG.8)
The self-evaporating system uses the collected water to cool the condenser coils for better efficient performance. It is no need to empty
the drainage tank in cooling operation except in drying operation and high humidity conditions. The condensate water evaporates at
the condenser and evacuated through the exhaust hose. For continuous operation or unattended operating in drying operation, please
connect the attached drain hose to the unit. Condensate water can be automatically flow into a bucket or drain by gravity.
5.13.1. Switch off the unit before operating.
5.13.2. Remove the plug of the water outlet opening, and keep it in safe area.
5.13.3. Securely and properly connect the drain hose and make sure it is not kinked and clear of obstruction.
5.13.4. Place the outlet of hose over a drain or bucket and ensure that water could freely flow out of the unit.
5.13.5. Do not submerge the end of hose into water; otherwise it can cause "Air Lock" in the hose.
5.13.5. To avoid water spillage:
• As the negative pressure of condensate drain pan is large, tilt the drain hose downward toward the floor. It is appropriate that the
degree of inclination should exceed 20 degrees.
• Straighten the hose to avoid a trap existing in the hose.
© Jack Sealey Limited
Press TIMER key
to turn on the timer
function
Press TIMER key
to turn on the timer
function
Press UP/DOWN repeatedly
until the LED shows '00'.
NOTE: pressing POWER will
also exit the timer setting.
C and the differential temperature between coil temperature and room temperature is below 19
o
MANUAL
DRAINAGE
Original Language Version
Press UP/DOWN
repeatedly to set the
delay OFF time.
Press UP/DOWN
repeatedly to set the
delay ON time.
FIG.8
CONTINUOUS
DRAINAGE
C, the unit restart to
o
C after the
o
SAC16000 Issue 1 03/01/24
