Everstar MPK-10CR-1 Use & Care Manual page 8

Key Pad Functions Fig.6
Power On/Off.
Selects the appropriate operating mode.
Cool-Dry (Dehumidify)-Fan
MODE Indicator Lights: Illuminates under the
different mode settings. Fig.7.
COOL Mode:
DRY(Dehumidifier)Mode:
FAN Mode:
Green Light : Remains on while compressor is
operating. Green light turns off when desired
temperature is achieved.
Water Full Indicator Light: Flashes red
when the water level of the water tank
exceeds the maximum set level or if the
water tank is not correctly positioned in the
cabinet. Fig. 8.
:Selects High-Medium-Low fan speeds
Fan Options: (High)
Cooling (3 speeds) High-Medium-LOW.
Dry-Dehumidifying (1 speed) High.
Fan (3 speeds) High-Medium-Low.
Used to adjust (forward) temperature
o o
settings (1 C/2 F increments).
Used to adjust (backward) temperature
o o
settings (1 C/2 F increments).
Note:
This appliance provides a feature that will allow
you the option of setting temperatures in
" "
Fahrenheit . To change the temperature display on the
"
main unit, press the
" "
simultaneously to alternate between the
scale. Celsius scale allows adjustments of 1
increments.
Fahrenheit scale allows adjustment of
o
2 F increments.
Green light
Green light
Green light
(Medium) (LOW)
"
Celsius
" " "
key pad & key pad
o o
C F
&
o
C
Green light while cooling
Green light while dehumidifying
Green light while fan only
O
C 10 11 12 13 14 15 16 17 18 19 20 21
O
F 48 50 52 54 56 58 60 62 64 66 68 70
O
C 22 23 24 25 26 27 28 29 30 31 32 33
O
F 72 74 76 78 80 82 84 86 88 90 92 94
LED Window: Shows the setting temperature
and Auto-On/Off time. While on DRY and FAN
"
or
mode, it shows the room temperature.
TIMER ON: Used to initiate the AUTO ON start
time program, and adjust Auto-Timer settings.
TIMER OFF: Used to initiate the AUTO OFF stop
time program, and adjust Auto-Timer settings.
6
The LCD window will shows
"P1" and the Water Full
indicator will flash every 0.5
seconds.
Temperature Conversion Chart
Fig.6
Fig.7
Fig.8
