Related Manuals for Tatu Marchesan COP FLEX

Summary of Contents for Tatu Marchesan COP FLEX

  • Page 2 IDENTIFICATION Dealer: Owner: Firm / Farm: City: State: No. of the Certificate of Guarantee: Serial / No.: Date: Invoice No.: Product: Notes:...
  • Page 3 Introduction COP FLEX and COP FLEX Suprema planters are specially designed to perform no-till or conventional planting of corn, soybean, rice, bean, peanut, delinted cotton, sorghum and others with superior quality. The permanent floating control assures that the row units will follow the soil profile.
  • Page 4 Calculation of seeds/meter according to the different number of holes Fertilizer distribution / Procedures to change the sprockets 51 & 52 Safety fuse of the transmission Fertilizer distribution table COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 5 Lubricate every 50 working hours Fertilizer metering maintenance Cleaning the seed metering Maintenance of the row hubs How to replace the tires Planter maintenance / Torque table COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 6: Table Of Contents

    Vacuum meter working preparation Vacuum meter recommendations / Troubleshooting tips Stopping the seed flow Troubleshooting 4. Safety stickers 5. Maintenance Pneumatic sealing / Seed metering maintenance 6. Important 7. Notes COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 7 NOTE which the original purchaser thereof, at retail, has used or allowed to be used parts, not made or supplied by Marchesan S/A. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 8 Have extreme caution when operating with the power take-off (PTO). Do not get closer during operation. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 9 For your protection and safety, always wear adequate clothes and footwear while operating the equipment. Always use the safety locks to carry out maintenance operations and to transport the equipment. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 10 Make sure the equipment is properly supported. • Please check the general safety instructions on the back cover of this manual. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 11 • Check all laws and regulations regarding the height limits and load width while transporting the equipment to the truck or trailer. If necessary use banners, lights and other devices in order to give adequate warning to the other drivers. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 12 These planters have adequate lifting points, being two in the rear and one in the front part of the equipment. When lifting with a hoist, it is essential to hitch the cables to these points. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 13 The seal must only be broken by the owner. El lacre podrá ser removido solamente por el propietario. 0 5 . 0 3 . 0 3 . 1 9 4 2 COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 14 0 5 . 0 3 . 0 3 . 1 4 2 4 Sticker set Model Serial number Serial number Serial number 05.03.03.3853 05.03.03.3854 05.03.03.3864 COP FLEX Small logo Big logo COP FLEX logo COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 15 11 - Hydraulic marker 12 - Transmission set 13 - Disc blade 14 - Tractor hitch pin 15 - Scarifier spindle 16 - Fertilizer dispenser 17 - Pressure adjustment lever COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 16 170 - 200 225 - 260 19/15 (3320) 750 (600) 19/16 800 (640) 19/17 850 (680) 19/19 950 (760) * According to the illustration on page 15 ("A" measure). COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 17 Measure (A) Measure (B) Measure (C) 4700 3300 2915 5500 4100 3715 6300 4900 4515 7200 5800 5415 8100 6700 6315 9000 7600 7215 9900 8500 8115 COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 18: Assembly

    A s s e m b l e t h e fixation support ( E ) a s f a r a s possible from the drawbar center. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 19 Use the same bolts (E) to lock the hose support (F), which can be found inside the components box. Fasten the upper part of the clamp (G) using bolts (H), flat washer and spring washer. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 20 Note that the squared tube on the frame has a tool box (F). To open it, remove the lock pin (G) that locks the box. After using it, the box must be locked again to avoid that it opens during transport/operation. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 21 3/8 X 1600 TR-TC hose Return 3/8 X 4200 TC-TM hose Pressure 3/8 X 4200 TC-TM hose Return Bidirectional flow divider valve Double connection Male quick coupler 1/2 NPT COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 22 Assembly Wheelset hydraulic circuit (9 - 11 row units) COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 23 3/8 X 1000 TR-TC hose Return 3/8 X 4200 TC-TM hose Pressure 3/8 X 4200 TC-TM hose Return Bidirectional flow divider valve Oil conductor Male quick coupler 1/2 NPT COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 24 Assembly Wheelset hydraulic circuit (13 - 15 row units) COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 25 3/8 X 750 TR-TC hose Return 3/8 X 4200 TC-TM hose Pressure 3/8 X 4200 TC-TM hose Return Bidirectional flow divider valve Oil conductor Male quick coupler 1/2 NPT COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 26 Assembly Wheelset hydraulic circuit (17 - 19 row units) COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 27 3/8 X 1000 TR-TC hose Return 3/8 X 4200 TC-TM hose Pressure 3/8 X 4200 TC-TM hose Return Bidirectional flow divider valve Oil conductor Male quick coupler 1/2 NPT COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 28 Use the extensor (K), bolt, lock and nut for planters that have 7 - 15 row units. The row markers have an independent lifting activation that can be activated NOTE without the need to lift or lower the equipment. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 29 Assembly Row marker hydraulic circuit (7 - 19 row units) COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 30 3/8 X 700 TR-TR hose Return 3/8 X 500 TR-TR hose 02 Pressure 1/2 X 4200 TC-TM hose Return 1/2 X 4200 TC-TM hose 01 Pressure Male quick coupler 1/2 NPT COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 31 3/8 X 1700 TR-TR hose Return 3/8 X 1700 TR-TR hose 02 Pressure 1/2 X 4200 TC-TM hose Return 1/2 X 4200 TC-TM hose 01 Pressure Male quick coupler 1/2 NPT COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 32 • Assemble the hydraulic cylinder (H) to the marker support (B) and to the marker arm (E). • Lastly, fasten the marker disc (I) to the extensor (F) and lock with a spring washer and nut. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 33 Loosen the nut and bolt (C) by doing the same procedure with the wrenches and thus releasing the row unit. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 34 (K). If the adjuster gets loose, fasten the thread until it tighten properly. Overtightening it may break the quick locking and the disc locking. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 35 . There are two hoses to raise or lower the planter and two to activate the row markers. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 36 Setting the planter in transport position After hitching the planter, totally lift the row units by activating the hydraulic cylinder. Lift the jacks (B), according to the illustration. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 37 During transporting and maintenance, always use the safety locks (C) on the hydraulic cylinder rods of the row markers and wheelsets. Only fill the planter in the work place. IMPORTANT Never transport the planter with load excess. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 38 Place the chain in the sprockets again. Release the lever by loosening the chain tightener pin. NOTE Turn the driven shaft always to the clockwise direction. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 39 Working preparation Spacing between row units COP FLEX planters leave the factory with a minimum row spacing according to the requested number of row units, allowing a possibility of other spacings if the crop needs it. Positioning the row units in the frame...
  • Page 40 Number of row units Spacings 750, 800, 850, or 900 650, 700 or 750 4845 Frame Number of row units Spacings 850 or 900 700, 750 or 762 5745 COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 41 550 or 600 Frame Number of row units Spacings 850 or 900 750 or 800 650 or 700 7545 Frame Number of row units Spacings 750 or 800 8445 COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 42 Check if the planter is properly supported to avoid accidents. The following instructions are necessary when placing or removing any row unit in the equipment. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 43 • Loosen the bolts and nuts from the drawbar (A), wheelsets (C), levers (D) and fertilizer row unit, so it is possible to move these parts on the frame. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 44 Assemble the hexagonal axle and check if it is turning freely. Fasten the bearings, tighteners and place the drawbar according to the instructions on pages 16 and 17. Always keep the greater spacing possible. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 45 • The tightening of the bearings that fasten the hexagonal axle should be done in the end. • Check the correct alignment of the chains (clutches/wheelsets). COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 46 Filled distance – Empty distance x 100 Empty distance The tires must have the same design, same inflation and same adjustment NOTE of springs over the wheelset arms. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 47 Tires: 7.00 x 16 - 10L, model RT 59 (maximum pressure: 75 PSI). Ideal working speed COP FLEX and COP FLEX Suprema planters work with higher efficiency from 5 to 7 Km/h. • Only fill up the planter on the work station.
  • Page 48 5.5 mm, place a false ring of 3 • Do not put a false ring if a plate that has 8.5 mm of thickness is used. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 49 For the soybean plate that features a double row of holes, it is necessary to use the double rocker arm (with two pulleys). COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 50 Therefore, it is always indispensable to make the practical distribution tests, as indicated on page 54. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 51                            COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 52 2.23 x 20 = 44.6 = 1.86 seeds per meter. Answer: Using a seed plate with 20 holes, 1.86 seeds per linear meter will be distributed (26x38 combination). COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 53 Therefore, it is always indispensable to make the practical distribution tests, as indicated on page 54. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 54 Safety fuse of the transmission To protect the seed and fertilizer system, the planter has safety fuses on the drive shafts and hexagonal shafts. Whenever necessary, replace for an original one. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 55 Adjustments and operations Fertilizer distribution table COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 56 • When there is a change in the batch of seeds as well as in the fertilizer manufacturer, everything must be assessed again. • It is important to assess all adjustments again after the first day of work. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 57 X = 1,125 grams in 50 meters in each row unit. Adjust the equipment to distribute the found amount or the best approximation in the delimited space for the test. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 58 T h e s e d i s c s f e a t u r e f l e x i b l e a n d adjustable internal scrapers (D) to remove earth that accumulate in their internal side. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 59 The fertilizer position related to the seed should be carefully observed. The NOTE ideal is to deposit the fertilizer twice as much of the seed depth. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 60 "2" - Smaller pressure. Holes in the lower bar of the parallelogram. "A" - Greater pressure. "B" - Smaller pressure. Set the same adjustment for every row unit. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 61 0.5 cm or 1 cm. The depth gauge wheels possess independent NOTE lateral and vertical oscillation to follow the differences of the ground ondulation. 0.5 cm 1 cm COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 62 While adjusting the press wheels it is important to consider the soil type, NOTE seed type and depth of planting to not affect the plants emergence. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 63 NOTE • Never start the job if the tires have different sizes/designs. • If necessary, put 3/4" of water on the tires and keep the same inflation. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 64 Transmission activation The free return of the transmission activation (C) must always be assembled as shown in the illustration below to work properly. Detail COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 65 (B) and when articulated, it must be locked by the lever (C). NOTE The platform (A) should only be used to fill up the planter. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 66 900 + 450 = 1,350 mm C = 1,350 mm This is the distance between the center of the first seed row and the marker disc lowered to the soil. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 67 Working angle The marker discs feature angle and distance adjustments to facilitate the soil opening. In order to do so, loosen the nut and adjust as necessary. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 68 • For adjustment and verification of the cutting parts (row units) of the equipment, it is necessary to disconnect the clutches to avoid wastes. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 69 05.03.01.6215 of 1 mm (Green) Ring for corn with recess 2 mm 05.03.01.6216 of 2 mm NOTE The blind seed plate has a diameter of 190 mm. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 70 Lastly, fasten the covering wheel set to the parallelogram arm (J) using a bolt (K), spring washer, flat washer and nut. The support (B) stays on the right or left side to relieve the planter tire. NOTE COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 71 The bolt (B) adjusts the pressure on the rod spring. To assemble the rod (A), fasten it on the arm of the fertilizer row using bolts (C), flat washers and nuts. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 72 Then, fasten the rod (D) to the fixation base (B) using a spring washer and nut. See the illustration below for the complete assembly. NOTE The depth control is done through the holes in the wheel support arm. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 73 • Fasten the covering wheels (D) to the depth control with thread (B) using bolts (E) and nuts. • Assemble the "V" rubber gauge wheels (F) to the gauge system (A), locking it using bolts (G) and spring washers. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 74 Lastly, fasten the depth control with angular adjustment and the "V" compactor (J) to the unaligned double seed disc (K) using bolts (L), spring washers and nuts. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 75 Assemble the "V" iron gauge wheels (D) to the depth control (B), locking it with bolts (E), flat washers, spring washers and nuts. Then, lock the unaligned double seed disc. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 76 The laced gauge wheels are factory fitted with wheel covers (F), which can be removed if necessary. Then, lock the seed unaligned double disc. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 77 • Allows the plantation at night with total precision, raising the planter income. For more information, consult the PM 100 manual or search for a local NOTE representative. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 78 • Allows the plantation at night with total precision, raising the planter income. For more information, consult the PM 400 manual or search for a local NOTE representative. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 79 • Every planter model can receive the hydraulic/electronic system to replace the mechanical transmission. Easy maintenance: • The color pattern of the cables and the diagnosis center in a single terminal station facilitates the discovery of possible problems. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 80 Optional TATU precision agriculture - Components connection Lifting sensor Seed sensor COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 81 The seed falls by gravity on this system with mechanical meter. NOTE Keep the seed conductor retainers (C) always tightened, in a way that they will not get loose during the plantation process. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 82: Maintenance 90

    Special attention should be given to the lubricant intervals on the ATTENTION different points of the planter. Lubricate every 10 working hours ATTENTION Lubricate the points shown above and all grease fittings as well. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 83 Maintenance Lubricate every 10 working hours ATTENTION Lubricate the points shown above and all grease fittings as well. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 84 Maintenance Lubricate every 50 working hours ATTENTION Lubricate the points shown above and all grease fittings as well. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 85 • Do not forget to lubricate the metering grease fittings daily, as mentioned on the 'lubrication' page, avoiding future problems. NOTE To improve the fertilizer dropping, use the fertilizer tube (I). COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 86 The hubs should rotate with the hand applying a small effort. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 87 (D) that are on the opposite side of the tire, releasing the bolt (E) and spring washer. Check if the planter is properly supported in order to avoid accidents. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 88 730 Ft. Lbs. 1450 Ft. Lbs. 1650 Ft. Lbs. 2307 Ft. Lbs. 2670 Ft. Lbs. GRADE 2 GRADE 3 GRADE 8 No Marks. 3 Marks. 6 Marks. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 89 Titanium Apollo Titanium Apollo COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 90: Seed Dosing System For Mechanical Machines

    Components and assembly Weight reducer Brush flow Neck Anti leap Flex brush View Base Seed plate seat COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 91: Working Preparation

    BEAN (MEDIUM) 70 holes 05.03.01.8468 SOYBEAN 80 holes 05.03.01.8483 BEET / ONION 32 holes 05.03.01.8496 SORGHUM 32 holes 05.03.01.8159 PEANUT 32 holes 05.03.01.8497 CANOLA 80 holes 05.03.01.8498 COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 92: Main Technologies

    (breaks, cracks and others) in the seeds and also raise the chances of the seeds to remain organized in the seed plate holes. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 93: Graphite Powder Use

    1/2 filled with seeds on a plastic bag (fertilizer bag, for example) and shaking to assure that all seeds will be equally lubricated. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 94: Precision Planting

    COP FLEX Suprema Precision Planting vacuum seed meter COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 95: Hydraulic Turbine Support Assembly

    (B), flat washer, turbine support fastener, spring washer and nut. • Then, assemble the turbine (C) to the turbine rear support (A), locking it with bolts (D), spring washer and nuts. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 96: Air Duct Assembly For A Single Seed Hopper System

    • Couple an adapter (I) on the outlet of the Precision Planting seed metering and couple a hose with clamp right after. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 97: Turbine With Hydraulic Motor / Hydraulic Activation

    For tractors which not have a direct free NOTE return (C) to the reservoir, it is necessary to consult your dealer to make the adaption. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 98: Row Unit Assembly (Rear Part)

    Then, lock the depth and gauge system (D) to the unaligned double disc (A) using bolts (E), spring washers and nuts. Lastly, lock the Precision Planting seed meter (F). COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 99: Coupling To The Free Return

    If there is any pressure on this hose, the hydraulic motor will be damaged. Couple the hoses from the hydraulic motor and from the planter cylinders to their respective hydraulic outlets on the tractor. Free return to the reservoir COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 100 Working preparation PRECISION PLANTING seed plates MARCHESAN optionally supplies seed plates for several cultures, according to the table below: COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
  • Page 101 Working preparation PRECISION PLANTING seed plates COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 102: Working Preparation 97 To

    Working preparation PRECISION PLANTING seed plates COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 103: Adjustments And Operations 101 To

    Therefore, it is always indispensable to make the practical distribution tests, as indicated on page 54. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 104: Seed Distribution Table

    D i s t r i b u i d o r Ta t u G I I P r e c i s i o n P l a n t i n g COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 105: Calculation Of Seeds/Meter According To The Different Number Of Holes

    • Constant speed of the planter: Corn / Sunflower = 5 to 6 km/h; Bean / sorghum / delinted cotton = 6 km/h; Soybean = 7 km/h. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 106: Changing The Metering Set

    Special attention should be given when placing the seed plate. Be sure to not curl or smash the seal. If there is any damage such as cracks or mends in the seal, replace it immediately. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 107: Baffle Position / Vdrive Components Maintenance

    • For some seed sizes it may be necessary to remove the baffle completely to prevent bridging of large seeds. • In some planting situations the owner should only replace the singulator, ejector or seed plate. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 108: Appropriate Suction / Vacuum Meter Suction Verification

    • If the rotation speed is not properly adjusted or is over 540 rpm, damages to the equipment or critical accident may occur. • Marchesan is not responsible for the inadequate use of its equipment. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 109: Vacuum Meter Installation And Assembly

    • Never use sharp objects to adjust, such as a switchblade. They may damage the seal. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 110: Vacuum Meter Recommendations / Troubleshooting Tips

    • Never clean the filter using tools. Remove it, wash with water and dry using compressed air. Never let water enter inside the vacuum meter, this act may damage ATTENTION your equipment and void your warranty. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 111: Stopping The Seed Flow

    (B) and release the butterfly nut to isolate the amount of seeds in the hoppers. After the inspection, tight the butterfly nut properly so it will not get loose NOTE during operation. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 112: Troubleshooting

    - Odd material in the fertilizer or - Check the fertilizer quality. Interruptions cobbled fertilizer. in the fertilizer metering - Deformed fertilizer tube. - Replace the tube. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 113: Safety Stickers

    0 5 . 0 3 . 0 3 . 2 9 4 9 Sticker set Model Serial number Serial number COP FLEX SUPREMA 05.03.03.3853 05.03.03.3854 logo TATU logo TATU logo 05.03.03.3890 Small sticker COP FLEX SUPREMA COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 114: Maintenance

    NOTE • Spray powder graphite in the pneumatic sealing (A). • Never use sharp or metallic objects to scrape the seed plates. COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 115: Important

    Marchesan Av., 1979 - P.O. Box 131 - Zip Code 15994-900 - Matão - SP - Brazil Telephone 55.16.3382.8282 - Fax 55.16.3382.3316 Sales 55.16.3382.1009 - Parts 55.16.3382.8297 - Export 55.16.3382.1003 e-mail: tatu@marchesan.com.br www.marchesan.com.br COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

  • Page 116: Notes

    Notes COP FLEX / COP FLEX SUPREMA Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
