- Page 1 30” Induction Range Installation Manual SKU #455-9999 / MODEL # CIR30B1S To reduce the risk of injury, user must read and understand operator’s manual. Save these instructions for future reference.
-
Page 2: Table Of Contents
Table of Contents Table of Contents..........2 Range Safety............3 Installation Requirements........5 Electrical Requirements........8 Installation Instructions........10 Required Set-up Procedure.......15 For questions, concerns, or for technical service, contact our customer service team via contact information below: Phone: 702-786-4996 Email: criterion-customer-service@outlook.com... -
Page 3: Range Safety
Range Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. THIS IS AN URGENT SAFETY ALERT SYMBOL. This symbol alerts you to potential hazards that can cause serious injury and/or death! All safety messages will be accompanied by this safety alert symbol as well as one of the following words:... - Page 4 Tip Over Hazard · Adults and/or children can seriously injured and/or killed in the event that this range tips over when handling due to the range not being secured properly to floor using the anti-tip bracket included. · Connect the anti-tip bracket to rear range feet per instructions in this manual.
-
Page 5: Installation Requirements
Installation Requirements Tools and Parts Some or all of the tools listed below may be required for installation. Read and follow all installation instructions using recommended tools Tools Needed • 15/16” Combination Wrench • Tape Measure • 3/8” Nut Driver •... - Page 6 Location Requirements Ventilation ! IMPORTANT ! Installer must review & comply with all governing federal and local codes & ordinances. It is the installers responsibility to comply with all designated clearance specifications for ventilation purposes included in these installation instructions, on the model/ serial rating plate, and/or within local code requirements.
- Page 7 Dimensions Opening For Product Installation Reference Opening dimensions shown are for 25" (64 cm) countertop depth and 24" 30" (77cm) D D i i m m e e n n s s i i o o n n (61 cm) base cabinet depth and 36" 5.9"(15cm) 30"...
-
Page 8: Electrical Requirements
Electrical Requirements Power Supply ! IMPORTANT ! To connect to an outlet in the wall, the electrical outlet must be recessed. If the electrical outlet is in the floor, it can be either recessed or surface mounted. 30" (76 cm) 17 ½"... - Page 9 federal, state and/or local codes/ordinances, in conformance to National Electric Code ANSI/NFPA No. 70 -latest edition. A copy of the federal code standards mentioned above can be obtained from your local authorities or from: National Fire Protection Association 1 Batterymarch Park Quincy, MA 02269 Phone: (617) 770-3000 ! IMPORTANT !
-
Page 10: Installation Instructions
Installation Instructions Excessive Weight Hazard · Use two or more people when unpacking and/or moving range for installation. · Failure to do so can result in back or other injury. Step 1 - Unpack Range 1. Remove all exterior shipping materials from range. 2. - Page 11 Tip Over Hazard · A child or adult can tip the range and be injured or killed. · Connect anti-tip bracket to rear range foot. · Reconnect the anti-tip bracket if the range is moved. · Failure to follow these instructions can result in death or serious burns to children and adults. ! IMPORTANT ! Do not completely remove the rear leveling leg.
- Page 12 Rear Wall Installation: Use the 2 screws provided or longer screws (if required) to secure the bracket to the sill plate of the wall structure using the pair of marked holes at LOC C. The screws MUST enter into a wood sill plate.
- Page 13 ! IMPORTANT ! Licensed electrician/installer must determine the proper electrical connection required for application. If installation application requires electrical connection other than utilizing the pre-installed 4-prong power cord, a licensed electrician MUST install in compliance with all federal, state and/or local codes/ordinances, in conformance to National Electric Code ANSI/NFPA No.
- Page 14 ! IMPORTANT ! If there is a snapping or popping sound when lifting the range, the range may not be fully engaged in the bracket. Check to see if there are obstructions keeping the range from sliding to the wall or keeping the range foot from sliding into the bracket. Verify that the bracket is held securely in place by the mounting screws.
-
Page 15: Required Set-Up Procedure
5. See manual to set correct time on control clock and to review instructions on using automatic cooking features. Important Note: Induction cooktop will only work properly with cookware designed for induction cooktops. For questions, concerns, or for technical service, contact our customer service team via contact information below: Phone: 702-786-4996 Email: criterion-customer-service@outlook.com...
