HEATING CONTROLLER Model FBSM V4
ATTENTION
Read carefully these instructions before installing and using this device and keep them for future reference. Attention to installation and electrical wiring. Use this
device only as described in this document and never use itself as a security device. The device must be disposed of in accordance with local standards for the collection
of electrical and electronic equipment.
DESCRIPTION
FBSM is a heating controller for heating rooms
either NTC scale -50÷+112°C (-58÷+230°F) or PTC scale -50÷+150°C (-58÷+302°F ) by adjusting a parameter.
INDICATIONS AND BUTTON OPERATIONS OUTSIDE THE PARAMETER'S MENU
PROGRAMMING THE PARAMETERS
By pressing [ ] we enter or exit the parameter's menu.
The first parameter "SPo" is displayed and with the [
By pressing [SET] the value of the parameter is displayed and with the [
By pressing [ ] we confirm the new value and the name of the parameter is displayed.
By pressing [SET] we cancel the new value, the old one is kept and the name of the parameter is displayed
SWITCHING ON/OFF THE DEVICE
By pressing more than 3 sec the button [
TECHNICAL SPECIFICATIONS
Power supply: 230VAC 50/60Hz / Maximum power consumption: 3W
It is recommended using a power supply safety fuse 0.5A (not included)
Cabinet's temperature sensor NTC 10K 1% 25
58÷+302°F) not included) / Accuracy: ±0.5°C
Heater relay 250VAC 30A resistive load
Relay for the cabinet lamp or fan ON/OFF 250VAC 10A
Connections: cable cross section
Connections with terminal blocks using cable with
Operating temperature: -15÷+70°C / Storage temperature: -20÷+80°C
The device is mounted through panel hole 29x71mm and is restrained with two plastic side brackets
Connection with terminal blocks 18A
CONNECTIONS - DIMENSIONS
ATTENTION: according to safety standards, the device must be properly positioned and protected from any contact with electrical parts. The device must be fastened in such a way that it cannot
be removed without the use of tools. Disconnect the main safety switch of the installation before proceeding to any maintenance. Disconnect the power supply of the device before proceeding to
any maintenance. Do not place the device near heat sources, equipment containing strong magnets, in areas affected by direct sunlight or rain. Prevent electrostatic discharges and sharp objects
from been inserted to the device. Separate signal cables from power supply cables to prevent electromagnetic disorders. Signal cables must never be in the same pipe with the power supply cables.
(bain-marie). It has 2 relays: one heater relay (30A) and one relay (10A) to control room's lamp or fan. The sensor can be
Indications
heater ON
fan ON
alarm ΟΝ
malfunction ON
], [ ] we scroll into the parameters based on the parameter's table below.
] we switch ON or OFF the device.
o C ΙΡ68 with temperature range -50÷+112°C (-58÷+230°F) (or PTC 1Κ 25
2.5 mm² for all relays / cable cross section
cable cross section
button
], [ ] we adjust the value.
from 0.25 to 1.0 mm² for the sensor
up to 2.5 mm² / It is recommended using a torque wrench with maximum torque 0.4Nm
Operations outside the parameter menu
pressed once
enter parameter's menu
temperature scale °C/°F
-
-
o C with temperature range -50÷+150°C (-
Firmware V4
pressed more than 3 sec
-
device ON/OFF
-
-
