Summary of Contents for Thomas Regout Winx-4b
- Page 1 Installation manual Winx-4b Fixed whiteboard expansion set item number: 481A93...
- Page 2 Winx-4b Fixed whiteboard expansion set General Warnings Tools...
- Page 3 Winx-4b Fixed whiteboard expansion set Content of the box (1x) (1x) (2x) F (2x) (2x) Content of “A”: [1:1] (8x) [1:1] (4x)
- Page 4 Winx-4b Fixed whiteboard expansion set Install Winx-4b Close the whiteboards as shown. Make sure top and bottom screws are tightened (4x) Remove the screws at the side of all hinges, save the screws (G) (8x) Save screw (G): [1:1] (8x)
- Page 5 Winx-4b Fixed whiteboard expansion set Mount 2x bracket (B) & 2x bracket (C) to the Winx-4b frame, use 8x screw (G) (2x) (1x) B (1x) (1x) C (1x) (2x) [1:1] (8x)
- Page 6 Winx-4b Fixed whiteboard expansion set Place whiteboard (F) between bracket (B) and (C) Use screw (D) to mount the whiteboard to bracket (B) and (C) (2x) (1x) F [1:1] (4x) Place whiteboard (F) between bracket (B) and (C) Use screw (D) to mount the whiteboard to bracket (B) and (C)
- Page 7 Winx-4b Fixed whiteboard expansion set Make sure the whiteboards are mounted parallel to each other Adjust if necessary Lock the position of each whiteboard by using 4x screw (F), use a power drill (1x) [1:1] (4x)
- Page 8 Regout Balance Systems B.V. Thomas Regout Inc. Industrieweg 40 145 Bluffs Court 6219 NR Maastricht Canton, GA 30114 The Netherlands...
