Problem
No output power
Generator resets
during activation
(Fault 100.10)
Red light illuminates
Unable to activate
the generator
Alarm tone too loud
or too quiet
No display on the generator
Generator flashes "Connect
Cable" after cable inserted
Generator flashes "Insert
Electrode" after electrode inserted and have not been damaged during reprocessing.
Generator overheats
(Fault 300.10)
Section 8
O
PERATING
T
ROUBLESHOOTING
Suggestions/Solutions
Check cables.
Check electrode connection.
Request assistance from service engineer.
Check grounding of generator.
Check insulation of connector cable.
Check integrity of electrode.
Ensure no contact was made with other equipment
during activation.
Refer to fault codes in Section 10 and request
assistance as necessary.
If your generator version supports both footswitch
and possible future handswitchable accessories
check that the correct activation source is selected.
Check footswitch for damage.
Ensure approved footswitch is attached.
Readjust volume by means of the mode switch.
Generator will remember the last volume
setting employed.
Check inlet fuses, replace with the correct type,
if necessary.
Request assistance from qualified service engineer
if fault persists.
Verify that the cable connector is fully inserted.
Check for damage to cable flex.
Remove connector and inspect pins for damage.
Ensure only GYNECARE VERSAPOINT approved
accessories are being used.
Ensure the connector contacts are clean and dry
Check electrode integrity.
Ensure only GYNECARE VERSAPOINT approved
accessories are being used.
Allow generator to cool down before re-use.
Check sufficient ventilation provided
around generator.
Ensure ambient temperature is within
operating limits.
