- Page 1 Installation Instructions / Warranty Interaktiv S 06462XXX...
-
Page 2: Product Specifications
Interaktiv S Single Control Kitchen Faucet 06462XXX Product Specifications: Hole size in mounting surface Minimum 1-1/2” Maximum mounting surface depth 2-3/8” Flow rate 2.2 GPM Maximum incoming water pressure 145 PSI Recommended incoming water pressure 22 - 72.5 PSI Recommended incoming hot water temp - 140 M3 cartridge with high temperature limit stop *Some governing bodies require that the water heater be set to 120... -
Page 3: Install The Faucet
Install baseplate 06329XXX, (optional - not included) Position the baseplate and gasket on the faucet deck. From under the sink, install the mounting flanges and tighten the mounting collars by hand. The baseplate can be used on a kitchen sink with fewer than three holes. Remove and disgard the threaded studs on the bottom of the baseplate. - Page 4 Connect the supply hoses: use 3/8” compression fittings (not included) to connect the hot and cold supply hoses to the stops. Use two wrenches, as shown in the diagram, to prevent the hoses from twisting. Install the hose weight: proper po- sitioning of the hose weight insures that the hose will retract smoothly.
-
Page 5: Replacement Parts
Replacement Parts handle 32892XXX nut cover 97995XXX 97996000 cartridge 92730000 handspray 97999XXX aerator 13912000 handspray hose 95048000 squeezing connection 96099000 mounting hardware 95049000 10 check valve 97350000 11 handle screw 96059000 12 supply hose 96316001 13 hose weight 98551000 XXX = color code 001 = chrome 801 = steel optik Troubleshooting... -
Page 6: Limited Lifetime Consumer Warranty
Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty. -
Page 7: To Obtain Warranty Service
THIS WARRANTY DOES NOT COVER and HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no rinse”... - Page 8 Hansgrohe, Inc. • 1490 Bluegrass Lakes Parkway • Alpharetta, GA 30004 Tel. 770 360-9880 • Fax 770 360 9887 www.hansgrohe-USA.com...
