Possibilities For Insertion - Zanussi ZGH76534XS User Manual

3.
min.
150 mm
min.
55 mm
30 mm
+ 2
480 mm
0
4.
If a furniture unit is installed at a
distance of 400 mm above the
hob, there must be a minimum
safety distance of 50 mm to the
left or right from the edge of the
hob.
5.
6.
min.
650 mm
2
+
560 mm
0
400 mm
50 mm
7.
8.
A. Supplied seal
B. Supplied brackets
9.
CAUTION! Install the appliance only
on a worktop with flat surface.

POSSIBILITIES FOR INSERTION

The panel installed below the hob must be easy to
remove and let an easy access in case a technical
assistance intervention is necessary.
A
B
9
