Product Description - Zanussi ZGH76534XS User Manual

Kitchen unit with door or drawer
B
min 5 mm
(max 150 mm)
60 mm
A. Removable panel
B. Space for connections

PRODUCT DESCRIPTION

COOKING SURFACE LAYOUT
1
CONTROL KNOB
Symbol
no gas supply / off position
ignition position / maximum
gas supply
10
min 6 mm
A
min 30 mm
2
3
4
5
Description
Kitchen unit with oven
The electrical connection of the hob and the oven
must be installed separately for safety reasons and
to allow for easy removal of the oven from the unit.
Kitchen unit with double oven
Multi Crown burner
1
Rapid burner
2
Semi-rapid burner
3
Auxiliary burner
4
Control knobs
5
Symbol
minimum gas supply
Description
