Wisi LR 2 Series User Manual

WISI VALUE LINE
User manual LR 2x series
fiber nodes for HFC/RFoG & RF Overlay
The LR 2x series of fiber nodes are optical nodes for HFC, RFoG or RF Overlay applications.
They can be operated in RFoG (burst-mode) and HFC (continuous wave) mode.
 High RF output level of 117 dBµV for
coaxial distribution of FTTC or FTTB signals
 DOCSIS-3.1-compliant frequency range:
Downstream up to 1.2 GHz, Upstream up
to 200 MHz
 Pluggable diplexers enable migration
towards DOCSIS 3.1 upstream
 Pluggable output splitters / taps for flexible
configuration of the two RF outputs
© WISI Communications GmbH & Co. KG
 Device control via bluetooth app or via
handset OH 41
 Optional: Remote control compliant to IEC
60728-14 via FSK receiver module
 Compact housing for outdoor deployment
(IP66)
 Powered locally (LR 2x 2xxx) or remotely
(LR 2x 6xxx)
 Optical ALC for regulated output levels
415 037 c
