SAFETY CHECK-OUT
After correcting the original service problem,
perform the following safety check before releasing
the set to the customer:
Check the antenna terminals, metal trim, "'metallized"
knobs, screws, and all other exposed metal parts for
AC leakage. Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to
earth ground and from all exposed metal parts to any
exposed metal part having a return to chassis, must
not exceed 0.5mA (500 microampers). Leakage
current can be measured by any one of three
methods.
1. A commercial leakage tester, such as the
Simpson 229 or RCA WT-S40A._ Follow the
manufacturers' instructions to use these instru-
ments.
ty
A battery-operated AC milliammeter. The Data
Precision 245 digital multimeter is suitable for
this job.
3. Measuring the voltage drop across a resistor by
means of a VOM or battery-operated AC volt-
meter. The "limit" indication is 0.75 V, so
analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa
SH-63Trd are examples of a passive VOM that
is suitable. Nearly all battery operated digital
multimeters that have a 2V AC range are
suitable. (See Fig. A)
To Exposed Metal
Parts on Set
AC
voltmeter
(0.75 V)
"= Earth Ground
Fig. A. Using an AC voltmeter to check AC leakage.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
TA-AV501/AV501R/AV601
SECTION 1
GENERAL
Parts identifications
21 [3] (15
POWER switch
SYSTEM POWER Switch (E model)
Remote control sensor
DRLC indicator (TA~AV601 only)
STANDBY indicator (TA- AV501R/TA-AV501: E model)
FUNCTION selectors and indicators
PRP) BE) ES &
DBFB (Dynamic Bass Feed Back) button and indicator
MUTING button and indicator (TA- AVS501R)
MASTER VOLUME control
DRLC/POWER switch (TA- AV601 only)
HEADPHONES jack (stereo phone jack)
[9] SPEAKERS A, B selectors
[10] BASS control
[11] TREBLE control
|12; BALANCE control
[13] INPUT BALANCE control
114; VIDEO 4 INPUT jacks
(15; SURROUND LEVEL +/-— buttons and indicators
16| DELAY TIME button and indicators
[17] SURROUND MODE selectors and indicators
