1/8-SCALE HIGH-PERFORMANCE 4WD ELECTRIC BUGGY RTR
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D'UTILISATION
MANUALE DI ISTRUZIONI
461784
Created 2/24
Scan the QR code and select the Manuals & Support tab from the
product page for the most up-to-date information.
Scannen Sie den QR-Code und wählen Sie auf der Produktseite die
Registerkarte Handbücher und Unterstützung, um die aktuellsten
Informationen zu erhalten.
Scannez le code QR et sélectionnez l'onglet Manuals and Support sur
la page du produit pour obtenir les informations les plus récentes.
Scannerizzare il codice QR e selezionare la scheda Manuali e Supporto
dalla pagina del prodotto per le informazioni più aggiornate.
LOS04019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Horizon Hobby 8IGHT-X LASERNUT
Summary of Contents for Horizon Hobby 8IGHT-X LASERNUT
- Page 1 1/8-SCALE HIGH-PERFORMANCE 4WD ELECTRIC BUGGY RTR Scan the QR code and select the Manuals & Support tab from the product page for the most up-to-date information. INSTRUCTION MANUAL Scannen Sie den QR-Code und wählen Sie auf der Produktseite die Registerkarte Handbücher und Unterstützung, um die aktuellsten BEDIENUNGSANLEITUNG Informationen zu erhalten.
-
Page 2: Table Of Contents
This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. -
Page 3: Water-Resistant Vehicle With Waterproof Electronics
Visit www.SpektrumRC.com for more information. WATER-RESISTANT VEHICLE WITH WATERPROOF ELECTRONICS Your new Horizon Hobby vehicle has been designed and built with a combination • Driving in wet conditions can reduce the life of the motor. The additional of waterproof and water-resistant components to allow you to operate the product resistance of operating in water causes excess strain. -
Page 4: Installing The Vehicle Batteries
INSTALLING THE VEHICLE BATTERIES Install two fully charged 3S batteries in the battery tray, and secure the Your vehicle is powered by two 3S LiPo batteries. We recommend two Spektrum ™ batteries with the hook and loop straps. 5000mAh 3S 11.1V Smart G2 100C; IC5 (SPMX53S100H5). Connect the batteries to the IC5 ESC power lead connectors. -
Page 5: Spektrum Dx3 Radio System
SPEKTRUM DX3 RADIO SYSTEM For more information on the transmitter, go to www.horizonhobby.com and click on the support tab for the Spektrum DX3 to download the instruction manual. A/B. Channel 3 Button Throttle/Brake Steering Wheel Steering Rate Adjusts the end point of the steering Brake Rate Adjusts the braking end point. -
Page 6: Operating The Vehicle
OPERATING THE VEHICLE • ALWAYS turn on your transmitter before you turn on the receiver in the vehicle. • ALWAYS power off the receiver before turning your transmitter off. Th Trim St Trim • ALWAYS operate your vehicle in a wide open area. Operating the vehicle in a small space or indoors can cause overheating at low speeds. -
Page 7: Spektrum Firma Smart 150A Brushless Esc (Spmxse2150)
SPEKTRUM FIRMA SMART 150A BRUSHLESS ESC (SPMXSE2150) ™ ™ SPECIFICATIONS ESC LED STATUS • No ESC LEDs will glow when there is no throttle input from the transmitter. Type Sensorless, SMART Throttle Compatible • The red ESC LED glows when there is any throttle input from the transmitter. Output 150A/950A AUDIBLE WARNING TONES... -
Page 8: Spektrum Firma 2050Kv 4-Pole Brushless Motor (Spmxsm1700)
DESCRIPTIONS Running Mode Max Brake Force - Forward Only with Brake: Intended for competition use, this mode allows Adjusts the maximum braking force. A higher value provides stronger braking, only forward and brake controls. but can also cause the wheels to lock, resulting in loss of control of the car. - Forward/Reverse with Brake: This mode is the basic all-around mode, Max Reverse Force allowing forward, reverse and brake controls. -
Page 9: Vehicle Maintenance
VEHICLE MAINTENANCE STOCK FLUIDS REQUIRED TOOLS The following items require semi-frequent maintenance. Always clean screw threads DIFF FLUIDS 1.5mm Hex Driver and apply removeable thread locking compound when threading machine screws Front 2.0mm Hex Driver into metal parts. Rear 2.5mm Hex Driver Center 200k 5.5mm Nut Driver... -
Page 10: Tuning, Adjusting & Maintaining Your Vehicle
Resolder the motor wire with the proper equipment Motor does not run Motor wire broken Repair or replace as needed ESC damaged Contact Horizon Hobby Product Support Motor over-geared Use smaller pinion or larger spur gear ESC gets hot Driveline bound up... -
Page 11: Limited Warranty
What this Warranty Covers any assistance. For questions or assistance, please visit our website at www. Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product horizonhobby.com, submit a Product Support Inquiry, or call the toll free telephone purchased (the “Product”) will be free from defects in materials and workmanship for... -
Page 12: Fcc Information
LOSI 8IGHT-X Super Lasernut Buggy RTR (LOS04019) EU Manufacturer of Record: Hereby, Horizon Hobby, LLC declares that the device is in compliance with Horizon Hobby, LLC the following: EU Radio Equipment Directive (RED) 2014/53/EU; RoHS 2 Directive 2904 Research Road 2011/65/EU;... -
Page 13: Exploded Views
EXPLODED VIEWS // EXPLOSIONSZEICHNUNGEN // VUES ÉCLATÉES // VISTE ESPLOSE FRONT DIFFERENTIAL // VORDERES DIFFERENZIAL // DIFFÉRENTIEL AVANT // DIFFERENZIALE ANTERIORE LOSA3501 TLR242045 TLR242045 LOSA3518 TLR242052 LOSA6948 TLR5963 LOS252147 LOSA6948 LOS252147 TLR242046 LOS252141 LOSA3505 TLR242045 TLR242052 LOSA3501 LOSA3518 LOS251132 TLR5910 LOS251132 TLR242019 LOSA6947... - Page 14 CENTER DIFFERENTIAL // ZENTRALES DIFFERENTIAL // DIFFÉRENTIEL CENTRAL // DIFFERENZIALE CENTRALE LOSA3501 TLR242045 TLR242045 LOSA3518 TLR242052 LOSA6948 TLR5963 LOSA3554 LOSA6948 LOSA3554 TLR242046 LOSA3555 LOSA3505 TLR242045 TLR242052 LOSA3501 LOSA3518 TLR5901 TLR255004 TLR5902 TLR5902 TLR6313 TLR244055 SPMXSE2150 LOS251134 TLR244055 LOS251131 LOS235024 LOS251134 SPMXSM1700 TLR5909 TLR5909...
- Page 15 REAR DIFFERENTIAL // HINTERES DIFFERENTIAL // DIFFÉRENTIEL ARRIÈRE // DIFFERENZIALE POSTERIORE LOSA3501 TLR242045 TLR242045 LOSA3518 TLR242052 LOSA6948 TLR5963 LOS252147 LOSA6948 LOS252147 TLR242046 LOS252142 LOSA3505 TLR242045 TLR242052 LOSA3501 LOSA3518 LOS235024 TLR244041 TLR244041 LOS254082 TLR244041 TLR244041 LOS250056 TLR242043 TLR244041 TLR5909 TLR244041 TLR244041 TLR5905 TLR244041 TLR245016...
- Page 16 LOS250059 LOS250060 TLR5962 LOS250062 TLR5962 TLR5962 LOS250063 LOS251132 LOS250060 ECX1050 LOS250063 LOS250062 TLR5909 LOS255028 LOS250062 LOS250059 LOS235024 TLR5906 LOS235024 TLR5909 TLR5902 TLR5962 LOS250062 LOS250063 TLR5962 TLR5909 LOS250062 TLR5903 LOS250059 LOS250064 TLR5902 TLR5909 LOS250058 TLR5903 TLR5962 TLR6352 LOS235024 TLR5902 LOS250062 LOS250061 TLR5906 LOS250058 LOS250057...
- Page 17 REPLACEMENT PARTS // ERSATZTEILE // PIÈCES DE RECHANGE // PEZZI DI RICAMBIO PART # DESCRIPTION BESCHREIBUNG DESCRIPTION DESCRIZIONE ECX1050 3x12mm Set Screw (4) Madenschrauben, 3 x 12 mm (4) Vis de fixation, M3×12 mm (10) Viti di fermo, M3x12 mm (4) LOS235007 Button Head Screws M4 x 12mm (10) Rundkopfschrauben, M4 x 12 mm (10) Vis à...
- Page 18 PART # DESCRIPTION BESCHREIBUNG DESCRIPTION DESCRIZIONE LOS255028 Button Head Screws M4x60mm (10) Rundkopfschrauben, M4 x 60 mm (10) Vis à tête bombée M4×60 mm (10) Viti testa tonda, M4x60 mm (10) LOS350007 Panel Set, Clear: SLN Panel-Set, klar: SLN Ensemble de panneaux, transparent: SLN Set pannelli, trasparente: SLN LOS45037 Wheel, Tire, Mounted(2): SLN Rad, Reifen, montiert(2)
- Page 19 PART # DESCRIPTION BESCHREIBUNG DESCRIPTION DESCRIZIONE 16mm Bleeder Shock Cap, Aluminum 16 mm Stoßdämpfer-Entlüfterkappe Capuchon d’amortisseur avec purgeur TLR243040 Tappi sfiato amm., 16 mm, alu (2): 8X (2): 8X Aluminium (2): 8X 16 mm, aluminium (2) : 8X Écrous d’amortisseur et joints toriques TLR243045 16mm Shock Nuts &...
-
Page 20: Recommended Parts
RECOMMENDED PARTS // EMPFOHLENE TEILE // PIÈCES RECOMMANDÉES // PARTI CONSIGLIATE PART # DESCRIPTION BESCHREIBUNG DESCRIPTION DESCRIZIONE Set gefräste Steckschlüssel (4) Jeu de clés à douille fraisées (4) Serie di chiavi a bussola fresate (4) DYNT2010 Machined Nut Driver Set (4) Metric metrisch métriques metriche... - Page 21 ©2024 Horizon Hobby, LLC. Losi, 8IGHT X, DSM, DSM2, DSMR, IC5, Dynamite, Fuze, Prophet, Firma, DX3, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc., and their respective logos are used under license by Horizon Hobby, LLC.
