Pioneer DMH-W3050NEX Operation Manual page 84

FM tuner
Frequency range:
87.9 MHz to 107.9 MHz
Usable sensitivity:
12 dBf (1.1 μV/75 Ω, mono, S/N: 30 dB)
Signal-to-noise ratio:
W3050NEX 2000NEX
50 dB (digital broadcasting) (IHF-A network)
50 dB (analog broadcasting) (IHF-A network)
W3000NEX
50 dB (IHF-A network)
AM tuner
Frequency range:
530 kHz to 1 710 kHz
Usable sensitivity:
28 μV (S/N: 20 dB)
Signal-to-noise ratio:
W3050NEX 2000NEX
45 dB (digital broadcasting) (IHF-A network)
45 dB (analog broadcasting) (IHF-A network)
W3000NEX
45 dB (IHF-A network)
Wi-Fi
W3050NEX W3000NEX
Version:
IEEE 802.11 a/n/ac (5 GHz)
Frequency channel:
149, 151, 155 ch (5 GHz)
Security:
WPA2 (Personal), WPA3 (Personal)
Output power:
+13.0 dBm Max (5 GHz)
GPS
GNSS receiver
System:
GPS L1C/Ac, SBAS L1C/A, GLONASS L1OF, Galileo E1B/C
SPS (Standard Positioning Service)
Reception system:
64 channel Multi-channel reception system
Reception frequency:
1 575.42 MHz/1 602 MHz
- 84 -
