Camera settings

A separately sold rear view camera is required for utilizing the rear view camera function.
(For details, consult your dealer.)
▶Rear view camera
This product features a function that automatically switches to the full-screen image of
the rear view camera installed on your vehicle when the shift lever is in the REVERSE (R)
position.
Camera View mode also allows you to check what is behind you while driving.
TIP
The parking assist guidelines can be displayed temporarily on the rear view camera screen by touching
the icon at the top left of the screen. When you reverse the gear and display the rear view camera
screen immediately after turning on the ignition switch, it takes approximately 10 seconds to be
available for the icon. The guidelines can be adjusted. For details on how to adjust the guidelines, see
[Parking Assist Guide Adjust] (page 64).
▶Camera for Camera View mode
Camera View can be displayed at all times. Note that with this setting, the camera image
is not resized to fit, and that a portion of what is seen by the camera is not viewable.
To display the camera image, touch [Camera View] on the source screen (page 49).
NOTE
To set the rear view camera as the camera for Camera View mode, activate [Back-up Camera Input]
(page 63).
CAUTION
Pioneer recommends the use of a camera which outputs mirror reversed images, otherwise the screen
image may appear reversed.
• Immediately verify whether the display changes to the rear view camera image when the shift lever is
moved to REVERSE (R) from another position.
Menu Item
[Back-up Camera Input]
[On] [Off]
[Back-up Camera view]
[Normal] [Reverse]
Description
Setting rear view camera activation.
Select the way the screen image of a camera appears.
- 63 -
