OPTIREG
linear voltage regulator TLS850F3TUVxx
™
demoboard
Z8F80607085
Preface
Scope and purpose
This document describes the usage of the OPTIREG
linear voltage regulator TLS850F3TUVxx demoboard for
™
the TLS850F3TUV33 and TLS850F3TUV50 from Infineon Technologies AG. Please also refer to the corresponding
datasheets.
Intended audience
This document is intended for engineers who develop applications.
User manual
Please read the sections "Important notice" and "Warnings" at the end of this document
Rev. 1.0
www.infineon.com/OPTIREG-linear
2024-05-08
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Infineon OPTIREG TLS850F3TUV Series
Summary of Contents for Infineon OPTIREG TLS850F3TUV Series
-
Page 1: Preface
This document describes the usage of the OPTIREG linear voltage regulator TLS850F3TUVxx demoboard for ™ the TLS850F3TUV33 and TLS850F3TUV50 from Infineon Technologies AG. Please also refer to the corresponding datasheets. Intended audience This document is intended for engineers who develop applications. -
Page 2: Table Of Contents
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 Table of contents Table of contents Preface ................1 Table of contents . -
Page 3: Introduction
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 1 Introduction Introduction General description The TLS850F3TUV33 and TLS850F3TUV50 are monolithic integrated low drop out voltage regulators for loads up to 500 mA in a PG-TO252-7 package (DPAK). With an input voltage range of 3 V to 42 V and very low quiescent current of only 26 µA, these devices are perfectly suitable for automotive or other supply systems connected to the battery permanently. -
Page 4: Block Diagram
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 1 Introduction Block diagram Current RO/WO Limitation Reset & Watchdog Primary Temperature Generator Reference Shutdown WINH Figure 1 Block diagram TLS850F3TUVxx User manual Rev. 1.0 2024-05-08... -
Page 5: Demoboard
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 2 Demoboard Demoboard Assembly There are two different demoboard assemblies available. One for the TLS850F3TUV33 and one for the TLS850F3TUV50. Figure 2 Assembly TLS850F3TUVxx demoboard User manual Rev. 1.0 2024-05-08... -
Page 6: Operating Conditions
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 2 Demoboard Operating conditions To avoid electrical damage of the demoboard, the values in Table 1 must be maintained. Table 1 Limit values for operation Parameter Symbol Values Unit Note or condition Min. -
Page 7: Configuration
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 2 Demoboard Configuration The demoboard has no configuration options. User manual Rev. 1.0 2024-05-08... -
Page 8: Signal Adaption
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 2 Demoboard 2.3.1 Signal adaption For easy signal adaption, for example connecting probes of an oscilloscope, test points are scattered across the PCB. The label of each test point indicates the probed signal. For further information on the mapping between test points and signals see Figure 4. -
Page 9: Connectors
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 2 Demoboard Connectors Table 2 Connectors and device pin mapping Label Function Regulator input WINH WINH Watchdog inhibit input: "Low" activates the watchdog function. "High" deactivates the watchdog function. This pin has an integrated pull-down resistor. Watchdog input: Serve watchdog with trigger input signal. -
Page 10: Schematic And Layout
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 3 Schematic and layout Schematic and layout Schematic The schematic in Figure 4 is assembled with either the TLS850F3TUV33 or the TLS850F3TUV50 mounted. Not mounted parts are optional and marked with a red cross. Figure 4 Schematic TLS850F3TUVxx demoboard User manual... -
Page 11: Layout
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 3 Schematic and layout Layout The PCB uses a four layer standard stack-up. The product can also be soldered to double layer boards. However, four layers offer better thermal characteristics. The configuration on this demoboard is comparable to the 2s2p thermal interface situation. - Page 12 OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 3 Schematic and layout Figure 6 Bottom layer TLS850F3TUVxx demoboard User manual Rev. 1.0 2024-05-08...
-
Page 13: Bill Of Materials
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 4 Bill of materials Bill of materials The bill of materials shows the components on the TLS850F3TUVxx demoboard. For the mounting condition of each component see Figure 4 Figure 5. Mechanical parts, such as connectors or test-points are not mentioned. -
Page 14: Restrictions
This demoboard offers limited features only for evaluation and testing of Infineon products. The demoboard is not an end product or finished appliance, nor is it intended or authorized by Infineon to be integrated into end products. The demoboard may not be used in any production system. -
Page 15: Revision History
OPTIREG linear voltage regulator TLS850F3TUVxx demoboard ™ Z8F80607085 6 Revision history Revision history Revision Date Changes 2024-05-08 Document created. User manual Rev. 1.0 2024-05-08... -
Page 16: Disclaimer
Infineon Technologies, All Rights Reserved. of any kind, including without limitation warranties of Infineon Technologies’ products may not be used in non-infringement of intellectual property rights of any any applications where a failure of the product or third party.
