SPECIFICATIONS
Amplifier Section
Continuous Average Power Output is 80
watts* per channel, min., at 8 ohms from 20
Hertz to 20,000 Hertz with no more than
0.05% ** total harmonic distortion.
Continuous Power Output (both channei driven)
1 kHz, THD. 6.05%, 82 BW + 95 Ww
Dynamic power (2/48 Q)} - 190/185/120 W
Total harmonic distortion (measured by Audio Spectrum Analyzer)
SIH2, BOWES Blv.5. eos oe estes eot eat tlgeko WONIS:
Input (Sensitivity/impedance)
PHONO MM + 2.5 mV/47 kQ
cD, VDP/CDY, VCR/TAPE 1, TAPE 2/DAT.
Phono Overload Level (7.H.D. 0.01%, 1,000 Hz}
.. 150 mV/22 k@
PHONO MM 130 m¥
Output {Level/Impedance}
TAPRESREG o o yse0t te cun oie eth AA cites) 150 mV/2.2 kQ
Frequency Response
PHONG: MMI: 20--ces2 spe ctv eeee 20 Hz to 20,000 Hz +0.5 dB
CD, VDP/CDY, VCR/TAPE 1, TAPE 2/DAT
sea teeac a d e tati .--. 10 Hz to 70,068 Hz *
Signat-to-Noise Ratio {IHF, short circuited, A network}
PHONO MM 73 dB
CD, VBP/CDV, VCR/TAPE 1, TAPE 2/DAT ... 96 dB
Signal-to-Noise Ratio [EIA, at 1 W (4 kHz}]
PHONO) MM 020. 5 ecssavetivdivivenscevinetacditentaceet does 7 odB
CD, VDP/CDV, VCR/TAPE 1, TAPE 2/DAT.........0---.- ee 79 dB
Graphic Equali 1 frequency band
100 Hz, 330 Hz, 1 kHz, 3.3 kHz, 10 kHz, +8 dB
* Measured pursuant to the Federal Trade Commission's Trade
Regulation rule on Power Output Claims for Amplifier.
** Measured by Audio Spectrum Analyzer.
FM Tuner Section
Frequency range
Usable Sensitivity
50 dB Quieting Sens:
87.5 MHz to 108 MHz
0.8 dBF, IHF {0.95 uV/75 Q)
svecseseeees- MONO: 16.3 dBf (1.6 2/78 9}
STEREO: 37.1 dBf (19.5 #V/75 Q)
Signal-to-Noise Ratio
MONG 0 eee ee eeerietesreneseeesee 80 OB (at 85 BFF
STEREO.. cevereeeseseee 76 GB (at 85 dBA
Distortion
STEREO... -0.3% (1 kHz}
Alternate Channel Selectivity 55 dB (400 kHz}
Stereo Separation ...35 dB (1 kHz}
Frequency Response ..........--.--.2-:eeeeeeee eee 3G Hz to 16 kHz, +1 dB
Output (FM 100% MOD)
REC OUT ....
Antenna input 300 @ balanced
75 Q unbalanced
AM Tuner Section
Frequency range
When 10 kHz step. decay 2.030 KHz to 1.700 kz
When 9 kHz step naaidevdaax eagle 531
kHz to 1,602 kHz
Seasitivity
IHF, Loop antenna 0... Seoesties nruateenten ere GUO EM,
SOlBCHYIEY: voces g o t nlececenniiiacas doh Seopieentecigs esa at ty 28 dB
Signal-to-Neise Ratio... dbeyadedthabunemetcans 56 dB
Output (AM 30% MOD) .
REC OU wa cyrees eee hee tastes oes s e e 1G MV
Antenna iecceAvees: Fs cw AM Loop Antenna
Video Section
Input (Sensitivity/Impedance)
VCR/TAPE 1, VDP/CDY..
Gutput (Level/Impedance}
VCR/TAPE 1, MONITOR pavecnecnd i 1 Vp-p/75 &
Frequency Response 0 10 He 6 Mz 2) dB
oT ¥o-p/78 Q
isolation at 3.58 MHz 60 dB
Signal-to-Noise Ratio 50 dB
Miscellaneous
Power Requirements
US., Canad MOTE ee AC 120 Volts, 60 Hz
Other mod: AC 10/120 — 127/220/240 V
(switchable), 50/60 Hz
Power Consumption
U.S. and Canadian models 000. 1 478 W, B15 VA
Other models...... sitatesvah lieasgnitse Jian OOD We
Dimensions ... ves. 420 (WY) & 120 (H} 7 (BD) min
16-9716 (WW) ™ 4-3/4 (HM) & 13-4/4 (D) in
Weight (without package)
US. and Cana
Other models
dian medels
8.2 kg (18 ib 2 oz)
8.3 kg (18 tb 5 oz}
Furnished Parts
FM T-type Antenna...... e i
AM Loop Antenna...
Gperating Instructions
Remote control unit...
Dry cell battery 000000...
oes ete!
NOTE,
Specifications and the design subject te possible modificatians
without notice due to improvements.
