- Page 1 PSEN ma1.3a/b-21 VA PSEN sensor technology Operating Manual-1004515-EN-03...
- Page 2 We do assure you that all persons are regarded without discrim- ination and on an equal basis. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for the user's internal purposes. Suggestions and comments for improving this documenta- tion will be gratefully received.
-
Page 3: Table Of Contents
Requirements and connection to evaluation devices ............10 Installation ..........................12 Adjustment ..........................15 Periodic test ..........................15 Dimensions in mm .........................15 Technical details ........................16 Safety characteristic data......................18 Order reference ........................18 System ............................18 EC declaration of conformity ....................19 UKCA-Declaration of Conformity ..................19 Operating Manual PSEN ma1.3a/b-21 VA 1004515-EN-03... -
Page 4: Introduction
PSEN ma1.3a/b-21 VA Introduction Validity of documentation This documentation is valid for the product PSEN ma1.3a/b-21 VA. It is valid until new doc- umentation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. -
Page 5: Safety
EN ISO 13849 and EN 62061. However, this does not guarantee the functional safety of the overall plant/machine. To achieve the relevant safety level of the overall plant/ machine’s required safety functions, each safety function needs to be considered separ- ately. Operating Manual PSEN ma1.3a/b-21 VA 1004515-EN-03... -
Page 6: Use Of Qualified Personnel
– If substitute actuators are used, these must be installed as described under Installation [ 13]. – If the original actuators are replaced with substitute actuators, the ori- ginal actuators must be destroyed before disposal. Operating Manual PSEN ma1.3a/b-21 VA 1004515-EN-03... -
Page 7: Unit Features
If the actuator is within the response range (safety gate closed), the safety contacts and the auxiliary contact on the safety switch will be closed and the LED will light. Operate the PSEN ma1.3a/b-21 VA in conjunction with the following components: Actuator PSEN ma1.3-08 VA (see... -
Page 8: Operating Distances
Assured release distance The offset-independent values for the switching distances are included in the Technical details [ 16]. Lateral and vertical offset Actuator PSEN ma1.3-08/VA Legend [1] Lateral offset [2] Vertical offset [3] Sensing faces Operating Manual PSEN ma1.3a/b-21 VA 1004515-EN-03... -
Page 9: Wiring
Green NOTICE The auxiliary contact with LED – may only be operated with a supply voltage of up to 24 VDC – cannot be connected in series – may not be used for safety circuits Operating Manual PSEN ma1.3a/b-21 VA 1004515-EN-03... -
Page 10: Requirements And Connection To Evaluation Devices
PSEN ma1.3a/b-21 VA Requirements and connection to evaluation devices For use of PSEN ma1.3a/b-21 VA in accordance with DIN EN 60947-5-3 an evaluation device must be connected. Connect the PSEN ma1.3a/b-21 VA either with a certified Pilz evaluation device or with an evaluation device with defined properties... - Page 11 (s. operating manual for the relevant evaluation device). PSENmag Evaluation device Input circuit Input circuit Fig.: Dual-channel connection PSEN ma1.3a/b-21 VA to the input circuits of an evaluation device Examples for connection to Pilz evaluation devices: PNOZ s3 PSENmag brown...
-
Page 12: Installation
If possible, do not install the safety switch and actuator on to ferromagnetic material. Changes to the operating distances are to be expected. Operating Manual PSEN ma1.3a/b-21 VA | 12 1004515-EN-03... - Page 13 Please note the installation measures in accordance with EN ISO 14119 for a proximity switch type 4 with coding level Low. Alignment errors of the guard must not adversely affect the safety function of the guard. Operating Manual PSEN ma1.3a/b-21 VA | 13 1004515-EN-03...
- Page 14 Sensing face Attach the actuator using 2 M12x1 hexagonal nuts. Also note the max. torque setting (see Technical details [ 16]). Operating Manual PSEN ma1.3a/b-21 VA | 14 1004515-EN-03...
-
Page 15: Adjustment
The safety functions should be checked after initial commissioning and each time the plant/machine is changed. The safety functions may only be checked by qualified personnel. Dimensions in mm Safety switch M12x1 Actuator PSEN ma1.3-08/VA M12x1 Operating Manual PSEN ma1.3a/b-21 VA | 15 1004515-EN-03... -
Page 16: Technical Details
In accordance with the standard IEC 60068-2-30 IEC 60068-2-30 Humidity 90 % r. h. at 40 °C 90 % r. h. at 40 °C Max. operating height above sea level 4000 m 4000 m EN 60947-5-3 EN 60947-5-3 Operating Manual PSEN ma1.3a/b-21 VA | 16 1004515-EN-03... - Page 17 Actuator dimensions Height 12 mm 12 mm Width 12 mm 12 mm Depth 25 mm 25 mm Weight of safety switch 120 g 220 g Weight of actuator 10 g 10 g Operating Manual PSEN ma1.3a/b-21 VA | 17 1004515-EN-03...
-
Page 18: Safety Characteristic Data
8 mm PSEN ma1.3a‑21/ Magnetic safety switch Cable, 5 m 526240 VA/1switch PSEN ma1.3b‑21/ Magnetic safety switch Cable, 10 m 526242 VA/1switch PSEN ma1.3-08/VA/ Actuator, with assured operating dis- 516140 1actuator tance 8 mm Operating Manual PSEN ma1.3a/b-21 VA | 18 1004515-EN-03... -
Page 19: Ec Declaration Of Conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma- chinery of the European Parliament and of the Council. The complete EC Declaration of Conformity is available on the Internet at www.pilz.com/downloads. Authorised representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ostfildern, Germany UKCA-Declaration of Conformity This product(s) complies with following UK legislation: Supply of Machinery (Safety) Regu- lation 2008. - Page 20 We are represented internationally. Please refer to our homepage www.pilz.com for further details or contact our headquarters. Headquarters: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: info@pilz.com, Internet: www.pilz.com...
