ROOMS TO GO 7725 Assembly Instruction

ROOMS TO GO
Manufactured for Rooms To Go
No. PARST LIST
A
HEADBOARD
B
LEFT LEG
C
RIGHT LEG
D
STRETCHER
E
FOOTBOARD
F
SLAT
G
CENTER LEG
H
SUPPORT LEG
I
SIDE RAIL
STEP 1
Part B Left Leg
1
Step 3 . Attach the headboard Stretcher (D) to headboard leg and secure
with flat washers, lock washers and bolts (1) using allen wrench (2) .
R
GLOB
Q'TY
1 PC
1 PC
1 PC
1 PC
1 PC
5 PCS
5 PCS
5 PCS
2 PCS
1
2
B
STEP 3
Part D Stretcher
2
ASSEMBLY INSTRUCTION
7725/7726-7 QUEEN UPH HEADBOARD
7725/7726-6 QUEEN FOOTBOARD WITH 5-SLATS
7725/7726-SR SIDE RAILS
HARDWARE PACKED IN HEADBOARD
No. HARDWARE LIST
1
2
HARDWARE PACKED IN FOOTBOARD
No.
HARDWARE LIST
3
Step 1 . Attach headboard left leg (B) to headboard and secure with
flat washers, lock washers and bolts (1) using allen wrench (2) .
Step 2 . Attach headboard right leg (C) to headboard and secure with
flat washers, lock washers and bolts (1) using allen wrench (2) .
A
D
STEP 2
Part C Right Leg
1
SKU# 32377257 / 32377269
SKU# 32777255 / 32777267
SKU# 32977259 / 32977261
BOLT 5/16" x 18 x 2"
LOCK WASHER 5/16" x 11 x 2mm
FLAT WASHER 5/16" x 19 x 2mm
ALLEN WRENCH (4mm)
SCREW 25mm
C
MADE IN VIETNAM
Q'TY
8 SET
1 PC
Q'TY
10 PCS
Page 1 of 3
