Piscine Solide V35042 Installation Manual

Oval pools
Hide thumbs

Advertisement

Quick Links

Download this manual
V35042
Mediterranean
POOL MODEL
INSTALLATION MANUAL - OVAL POOLS
11.13

Advertisement

loading
Need help?

Need help?

Do you have a question about the V35042 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Piscine Solide V35042

Summary of Contents for Piscine Solide V35042

  • Page 1 V35042 Mediterranean POOL MODEL INSTALLATION MANUAL - OVAL POOLS 11.13...
  • Page 3 Above Ground Pool SAfety PleASe reAd before inStAllAtion Failure to heed these warnings can result in permanent injury, warning paralysis From a broken neck, electrocution or drowning. this pool is not designed For diving or jumping! dangerous injury can result, shallow water! your pool contains a large quantity of water, and is deep enough to present inherent dangers to life and health unless the follow- ing safety rules are strictly observed.
  • Page 5 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION Read all instructions completely before you begin. A. DETERMINE THE LOCATION OF YOUR POOL 1. The Terrain Pay special attention to choosing the right location for your pool: • Choose a large area, as flat and level as possible and well drained.
  • Page 6 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION A. CONT. DETERMINE THE LOCATION OF YOUR POOL 2. Things to Avoid Do not locate your pool near or on any of the following (Images 3a to 3c) • Overhanging tree branches. •...
  • Page 7 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION A. CONT. DETERMINE THE LOCATION OF YOUR POOL 4. Tools Needed List of required materials • Straight wood plank • Material that provides a permanent base (ex. Crushed stone) • Fine sand (void of debris) •...
  • Page 8 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION PARTS LISTING - EXPLODED VIEW Mediterranean / Magnus RTR PMAG-YE54RSRSRSB10 Yard Extender Important Note: Make sure you have all the parts necessary before you Oval start installation. Important Note: Do not throw away the extruded polystyrene sections. No Diving or Jumping.
  • Page 9 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION PARTS LISTING - CONTENTS Product Description : Magnus Oval Revised Sept 2013 Product Code : PMAG-YE54RSRSRSB10 Index# Description Parts # Length 1223 1526 1530 1833 Top ledge (round sections) AR744-001-R Top ledge (straight sections) AR744-001-45 45'' Upright...
  • Page 10 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. PREPARE THE FOUNDATION OF YOUR POOL 1. Mark out the Area The next following steps will show you how to mark out the area you need for the oval pool. This marked area will be larger than the pool size itself, but this space is needed.
  • Page 11 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. CONT. PREPARE THE FOUNDATION OF YOUR POOL Mark areas along both straight sides of your oval. Use pegs and string as a guide for the can of spray paint to mark straight lines. (Image 5) You now have the space marked out that is needed for your oval pool.
  • Page 12 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. CONT. PREPARE THE FOUNDATION OF YOUR POOL Example on how to mark out pool area for an 18 x 33 Please be sure to use your pool’s footprint for your pool size on the last pages of this Section1.
  • Page 13 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION B. CONT. PREPARE THE FOUNDATION OF YOUR POOL 3. Make the area flat and level Remove all the high spots with a shovel, hoe or rake. To make sure your pool is stable, compact the ground well before adding the sand.
  • Page 14 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION C. PRE-ASSEMBLY OF THE T JOINTS (BUTTRESS) 1. Assembling the buttress joints Insert the horizontal sleeves in the buttress joints. Outside of Pool On each side insert two or three (depending on the Inside of Pool side) 6.35 cm (2.5”) mechanical screws with nuts.
  • Page 15 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION C. CONT. PRE-ASSEMBLY OF THE T JOINTS (BUTTRESS) Insert the three 6.35 cm (2.5”) screws with nuts in Outside of Pool the vertical sleeve. (Image 14) Inside of Pool IMPORTANT: If your pool has steel bottom plates, Do not permanently fasten the vertical sleeve with screws.
  • Page 16 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section Section GROUND PREPARATION D. GROUND PREPARATION FOR THE BUTTRESS 1. Measuring for the buttress trenches In order to measure where trenches need to be dug for the placement of the buttress, you must first draw a perpendicular line in order to create a perfect 90 degree angle.
  • Page 17 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION D. CONT. GROUND PREPARATION FOR THE BUTTRESS 2. Digging the buttress trenches Odd number of trenches; If your oval pool contains an even number of buttresses, please proceed with next step. If your oval pool contains an odd number, position the buttress temporarily on the straight center line from the middle.
  • Page 18 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION D. CONT. GROUND PREPARATION FOR THE BUTTRESS 3. Install Patio Stones (Blocks) Insert and level two concrete slabs or their equivalent, which should measure about 20 cm x 40 cm x 10cm (8” x 16” x 2”), allowing one of the slabs to extend past the inside end of the T.
  • Page 19 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION D. CONT. GROUND PREPARATION FOR THE BUTTRESS 4. Finish trenches & patio stone installation Continue to finish one by one the remaining trenches with patio blocks for the buttress installation. It is important to finish one side of the oval only.
  • Page 20 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION E. ASSEMBLING THE BUTTRESS STRAPS AND PRESSURE PLATES 1. Assemble the buttress straps and brace Place a steel strap and a pressure plate on the buttress base, 1.14 m (45”) from centre to centre, place only one screw, but do not secure it tightly.
  • Page 21 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION E. ASSEMBLING THE BUTTRESS STRAPS AND PRESSURE PLATES Once both sides of the buttresses have been installed perfectly, check that all is measured again perfectly. (Image 28) Add the remaining straps that join across to other straps.
  • Page 22 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 10 x 16 - For PZEN-YE52/54SSPSPSB10/11 & 52/54RSPSPSB10 10'-7 1/8" 4'-11 3/4" 4 places 13'-11 3/4" 1-18 No Diving or Jumping. Observe all Safety Rules...
  • Page 23 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 12 x 19 - For PZEN-YE52/54SSPSPSB10/11 & 52/54RSPSPSB10 12'-1 5/16" 2'-2 1/8" 2places 4'-11 3/4" 4places 15'-5 15/16" 1-19 No Diving or Jumping. Observe all Safety Rules...
  • Page 24 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 12 x 23 - For PZEN-YE52/54SSPSPSB10/11 & 52/54RSPSPSB10 12'-1 5/16" 2'-2 1/8" 3 places 4'-11 3/4" 6 places 15'-5 15/16" 1-20 No Diving or Jumping. Observe all Safety Rules...
  • Page 25 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 15 x 26 - For PZEN-YE52/54SSPSPSB10/11 & 52/54RSPSPSB10 14'-10 15/16" 4'-11 3/4" 9 places 18'-3 9/16" 1-21 No Diving or Jumping. Observe all Safety Rules...
  • Page 26 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 15 X 30 - For PZEN-YE52/54SSPSPSB10/11 & 52/54RSPSPSB10 14'-10 15/16" 4'-11 3/4" 12 places 18'-3 9/16" 1-22 No Diving or Jumping. Observe all Safety Rules...
  • Page 27 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 18 x 33 - For PZEN-YE52/54SSPSPSB10/11 & 52/54RSPSPSB10 17'-11 3/8" 2'-2 1/8" 8 places 4'-11 3/4" 12 places 21'-4" 1-23 No Diving or Jumping. Observe all Safety Rules...
  • Page 28 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 12 x 19 - For PZEN-YE54RSRARSB11 12'-1 5/16" 2'-2 1/8" 3 places 4'-11 3/4" 6 places 15'-5 15/16" 1-24 No Diving or Jumping. Observe all Safety Rules...
  • Page 29 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 12 x 23 - For PZEN-YE54RSRARSB11 12'-1 5/16" 2'-2 1/8" 4 places 4'-11 3/4" 8 places 15'-5 15/16" 1-25 No Diving or Jumping. Observe all Safety Rules...
  • Page 30 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 15 x 26 - For PZEN-YE54RSRARSB11 14'-10 15/16" 4'-11 3/4" 9 places 18'-3 9/16" 1-26 No Diving or Jumping. Observe all Safety Rules...
  • Page 31 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 15 X 30 - For PZEN-YE54RSRARSB11 14'-10 15/16" 4'-11 3/4" 16 places 18'-3 9/16" 1-27 No Diving or Jumping. Observe all Safety Rules...
  • Page 32 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section GROUND PREPARATION OVAL FOOTPRINT - 18 x 33 - For PZEN-YE54RSRARSB11 17'-11 3/8" 2'-2 1/8" 10 places 4'-11 3/4" 15 places 21'-4" 1-28 No Diving or Jumping. Observe all Safety Rules...
  • Page 33 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS 1. Bottom plates - STRAIGHT SECTION-STEEL NOTE: Depending on your pool model you may have steel or resin bottom plates. IMPORTANT: Insert a Junction rail into either side of the bottom rail in the straight section only, before inserting into either side of the bottom plate.
  • Page 34 IMPORTANT NOTE There are three types of bottom rails; 1- Straight Section 2- Round Section 3- Transition (End of the Straight Section). To differentiate which bottom rail is which; • The Straight Section will measure the shortest in length • The Transition Section will measure will measure longer than the straight section, but shorter than the round section. • The Round Section will be the longest measurement. Straight Section Transition Section Round Section Junction...
  • Page 35 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS Insert the assembled bottom plate with bottom rail into the vertical uprights. It is preferable to be two persons to accomplish this step. (Images 3 to 5) Replace the vertical sleeve and attach with the 3 screws and nuts.
  • Page 36 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS 1. Bottom plates - STRAIGHT SECTION - RESIN NOTE: Depending on your pool model you may have steel or resin bottom plates. To install the bottom plate in the straight section, you need to remove the centralplate of the bottom plate with a hammer or pliers.
  • Page 37 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS STEEL 2. Bottom plates - ROUND SECTION NOTE: Depending on your pool model you may have steel or resin bottom rails Continue the installation of the bottom plates of the round sections.
  • Page 38 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF BOTTOM PLATES AND BOTTOM RAILS 3. Patio Stones (Optional) Contact your Dealer: Please contact your dealer for more information about using patio stones. Concrete patio stones may be placed at the base of each upright of your pool.
  • Page 39 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL BASE A. CONT. INSTALLATION OF OF BOTTOM PLATES AND BOTTOM RAILS 4. Measure the perimeter of your pool Measure the perimeter of your pool and hammer nails into the ground to keep the bottom rails into place.
  • Page 41 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL A. SETTING UP THE POOL WALL Do not attempt to install the pool wall in the wind, wait for a calm day. It takes at least 3 people to install the pool wall. 1.
  • Page 42 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL A. CONT. SETTING UP THE POOL WALL 3. Join the ends of the pool wall Line up the holes in the two ends of the pool wall. (Image 4) Now that you have installed the wall you can be faced with three scenarios.
  • Page 43 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL A. CONT. SETTING UP THE POOL WALL To fasten the wall joint, overlap the two steel bars, one on the inside and the other on the outside. Tighten the mechanical screws on the inside and the nuts on the outside.
  • Page 44 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL B. ASSEMBLING THE COVE 1. Make the cove If you are using sand, bank the sand against the wall to form a cove of 3” to 6” (7.5cm to 15cm) high and 8”...
  • Page 45 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL B. CONT. ASSEMBLING THE COVE A vacuum cleaner can later be used to remove the air from between the liner and the wall. This technique enables you to remove folds in the liner. (Image 12) However the following precautions should be taken: Do not use an industrial vacuum cleaner which...
  • Page 46 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. INSTALL THE POOL LINER 1. Set the liner in place Open the carton. Do not use anything sharp to open the carton. Unpack and unfold the liner and spread it out in the sun to warm it up.
  • Page 47 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER Please ensure to follow instructions that match the type of liner you may have. 2. Fasten the liner place (OVERLAP ONLY) Starting at the liner wall seam, hang the liner over the wall making sure that the seam is straight up and down, perpendicular to the floor.
  • Page 48 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER After all the wrinkles in the liner are removed, trim any extra length of plastic coping so there is no overlap. (Image 19) Roll up any excess liner hanging below the plastic coping and tape it in place near the top of the pool wall.
  • Page 49 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER 4. Fasten the liner in place (HUNG/J or V-BEAD LINER ONLY) With a V-Bead liner you will not use the plastic coping strips that are packed in the parts carton of your pool.
  • Page 50 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL WALL C. CONT. INSTALL THE POOL LINER 3. Fasten the liner place (BEADLOCK/SNAPBEAD LINER ONLY) With a snap bead liner you will not use the plastic coping strips that are packed in the parts carton of many pools.
  • Page 51 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME A. INSTALLATION OF THE UPRIGHTS - Straight Section 1. Install the uprights - Straight Section NOTE: Depending on your pool model you may have steel or resin bottom plates/rails. The wall joint is hidden behind the upright on most pools.
  • Page 52 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME A. CONT. INSTALLATION OF THE UPRIGHTS - Round Section 1. Install the uprights - round section NOTE: Depending on your pool model you may have steel or resin bottom plates. The wall joint is hidden behind the upright on most pools.
  • Page 53 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS ASSEMBLING THE POOL FRAME A. CONT. INSTALLATION OF THE UPRIGHTS 2. Install the footcovers (NOT INCLUDED in Magnus Pool) If your model contains the optional footcover, attach with self-tapping screw. Round Section: Image 5 Straight Section Image 6 Install the nishing plug.
  • Page 54 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME B. INSTALLATION OF THE STABILIZERS AND TOP PLATES - Straight Section 1. Install stabilizers and top plates - Straight Section STEEL Only Install the stabilizers on the wall while ensuring to leave a gap between each end.
  • Page 55 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME B. INSTALLATION OF THE STABILIZERS AND TOP PLATES - Straight Section 1. Install stabilizers and top plates - Straight Section RESIN Only Install the stabilizers on the wall while ensuring to leave a gap between each end.
  • Page 56 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME B. INSTALLATION OF THE STABILIZERS AND TOP PLATES - Round Section 2. Install stabilizers and top plates - Round Section NOTE: Depending on your pool model you may have steel or resin top plates.
  • Page 57 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. INSTALLATION OF TOP LEDGE AND LEDGE COVERS 1. Install top ledge NOTE: Depending on your pool model you may have steel or resin top ledge. Place top ledges on the wall. Align the holes on the top ledges with those on the top plates.
  • Page 58 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF TOP LEDGE AND LEDGE COVERS 2. Install ledge covers NOTE: Depending on your pool model you may have steel or resin top ledge. Place interior ledge cover onto the top plate and attach with a slef-tapping screw.
  • Page 59 GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME C. CONT. INSTALLATION OF TOP LEDGE AND LEDGE COVERS Attach the exterior ledge cover to the upright using a self-tapping screw. ( Image 26) Install the finishing plug on the ledge cover. Image 27) No Diving or Jumping.

  • Page 60: Important Safety Information

    GENERAL INSTRUCTIONS - BRACELESS OVAL POOLS Section ASSEMBLING THE POOL FRAME D. FILL YOUR POOL WITH WATER 1. Finish filling the pool Turn off the vacuum and carefully remove it from the pool. Fill the pool with water to 2” (5cm) below the lowest opening.
