ASROCK P43ME Brochure

P43ME
®
Intel P43+ ICH10 Chipsets
Product Brief
- Supports FSB1600 MHz CPUs
- Supports Dual Channel DDR2 1200
- PCIE Gigabit LAN
- 7.1 CH Windows ® Vista™ Premium Level HD
Audio (VIA ® VT1708S Audio Codec with QSound)
- Supports ASRock Instant Boot, Instant Flash,
OC Tuner, Smart BIOS, Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
w ww.as rock.com
Detail Specification
- Micro ATX Form Factor: 9.6-in x 8.3-in, 24.4 cm x 21.1
Platform
cm
CPU - LGA 775 for Intel
Core TM 2 Duo / Pentium
®
/ Celeron , supporting Penryn Quad Core Yorkfield and
Dual Core Wolfdale processors
- Supports FSB1600/1333/1066/800 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel
Chipset
- Southbridge: Intel
- Dual Channel DDR2 memory technology
Memory
- 2 x DDR2 DIMM slots
- Supports DDR2 1200/1066/800/667 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express 2.0 x16 slot (green @ x16 mode)
Expansion Slot
- 1 x PCI Express 2.0 x1 slot
- 2 x PCI slots
Audio - 7.1 CH Windows
(VIA ® VT1708S Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
Connector - 6 x SATAII 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Print port header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 8Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 2.3.1 Support
- CPU, VCCM, NB, VTT Voltage Multi-adjustment
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
- Microsoft ® Windows
TM
Vista 64-bit compliant
- FCC, CE, WHQL
Certifications
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 133 Cable
- 2 x SATA Data Cables (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
® Core TM 2 Extreme / Core TM 2 Quad /
® Dual Core / Celeron ® Dual Core
® P43
® ICH10
®
Vista™ Premium Level HD Audio
® 2000 / XP / XP 64-bit / Vista TM /
