Abus ABUECFA3010 Manual

ABUS
Hometec Z-Wave Door Lock
SKU: ABUECFA3010
Quickstart
This is a secure Door Lock for Europe. To run this device please insert fresh 4 * AA batteries. Please make sure the internal battery is fully charged. Push
the two arrow buttons for 3 seconds until the left green LED lights up. This indicates the management mode. Clicking on the 'Lock' button includes the
device. The right green LED indicates rediness to include. Clicking the 'unlock' button wil terminate the inclusion mode and also the management
mode. The device supports the Security S2 framework with Access Control network keys. Please note that your gateway/controller MUST support S2 in
order to use this product. If you own a legacy controller without Support for S2 please enable fallback to S0 security as described in Section
'Installation'. The device also supports Smart Start. Please scan the QR code on the outlet cover of the device and your controller will add the the device
automatically when powered up.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified
Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The HomeTec Z-Wave wireless door lock actuator is system designed for retrofitting to doors that open inwards to provide motorised locking and unlocking
functions. The door can be electronically operated using local buttons and any Z-Wave device capable to control door locks. For the wireless door lock actuator to
work, the cylinder must project 7-12 mm on the inside of the door (plus the thickness of the fitting or collar). Because the actuator operates with a key permanently
inserted in the lock, the cylinder must have an "emergency" feature where the door can be opened with a key from the outside even when another key is inserted
on the inside. In addition, the door lock must be a profile cylinder compliant with DIN 18252.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
• Enable management mode by holding down '<' and '>' for 3 seconds. Green left LED will light up to confirm management mode.
• Move in this menu by pushing '<' or '>' Arrows. The left LED will change its color to indicate different menu items. left LED =
green: Learn Mode, left LED = red: Reset Mode
• Enter the menu, where left LED is RED, by pushing '<' or '>' Arrows.
• Hit 'Enter' (door close button). The right LED will change its color to indicate different reset options. right LED = green: Reset
only Lock, right LED = yellow: Reset only Z-Wave, right LED = red: Reset Lock and Z-Wave
• Using the keys '<' and '>' you can change the setting. Change the setting to be YELLOW (Reset Lock and Z-Wave)
• Push the Enter-button for 3 seconds until both LEDs are flashing.
• Push the Enter-button again for 3 seconds to confirm the reset to factory default.
All settings are deleted.
