- Page 1 PLS67-175 Battery powered lift Instructions Version Presto Lifts Inc. 50 Commerce Way, Norton MA 02766 1-800-343-9322 Fax: 1-888-788-6496...
-
Page 2: Table Of Contents
Contents 1. Specifications .............................. 3 2. General safety precautions during use ......................3 2.1. Safety systems ............................. 3 3. Application ..............................3 4. Operating the Lifter ............................4 4.1. The remote control symbols ........................4 5. Batteries and charger ........................... 5 6. -
Page 3: Specifications
1. Speci cations Medium High Weight (kg) PLS67-175 Max. load (kg) PLS67-175 Protection class IP41 Batteries Type VRLA 24V, 9.0 Ah or 24V,18AH (maintenance free) Charger 230V – 2 A or 230V – 3A Charging time 4-5 hours (80%) 8 hours (100%) Sound pressure level ≤... -
Page 4: Operating The Lifter
4. Operating the Lifter Some models are operated using the switch located on the lift's control panel on the mast: The lifter will lift while the button is pressed The lifter will lower while the button is pressed If the lift is delivered with lifting equipment, specific operating instructions are required. Some models with electric tools are operated using a remote control with a spiral cord. -
Page 5: Batteries And Charger
5. Batteries and charger Battery indicator The lift is equipped with a battery status indicator that indicates the battery status when the lift button is activated. Red indicator: Batteries must be recharged immediately. Green indicator: The batteries are functionally charged. The lift is charged with a built-in 230V charger. -
Page 6: Resolving Faults
8. Resolving faults Fault type Check the following Solve The timing belt jumps on Is the belt slack? Tighten the belt using the two screws at the belt wheel (the belt is the top of the mast. making crackling noises) Is the belt worn? Replace the belt The belt is skewed (the belt... -
Page 7: Lifting Equipment
9. Lifting equipment The sledge on the lift are equipped with holes for mounting accessories and tools, as described below. 9.1. Forks and platforms Application The forks (G) can be in painted steel or stainless steel. Platforms can be in PEHD (KP) or stainless steel (EP). -
Page 8: The Gripping Device Qc - Eg
9.5. The gripping device QC - EG Application The gripping device is used to handle items which, due to their shape, are difficult to handle. These may typically be containers, vessels or drums. The gripping unit is used in combination with a turning or tipping device. QC6 = Quick clamp with turning unit EG6 = linear clamp with turning unit EG8 = linear clamp with tipping unit... -
Page 9: Turning Device
9.6. Turning device Application The turning device is used to rotate an item. It is often used in combination with a gripping device QC or Operation The turning device is available as an electrical rotational function. Optional with electronic stop at 0° and 180° To operate the electrical turning function, button 3 and 4 on the remote control are used for left and right rotation respectively. -
Page 10: Tipping Device
9.7. Tipping Device Application The tipping device is used to empty or tip items in a forward direction, typically for pouring liquids from containers or tanks. Operation The tipping unit has an electrical tipping functionality. To operate the electrical tipping function, button 3 and 4 on the remote control are used for forward and reverse rotation respectively. -
Page 11: Reel Handler
9.9. Reel Handler Application The Reel Handler is used to handle reels of stretch film. The forks are leveled vertically to fit the top and bottom of the reel with stretch film. The reels can be taken directly from the pallet or from the floor. The truck is pushed forward so that the fork gets hold of the reel. -
Page 12: Wiring Chart
PLS67-175 10. Wiring Chart Page 12... -
Page 13: Load Diagram
12. Load diagram Max weight on lift with mass center x mm from mast PSL67-175 PSL67-175 Page 13...
