Summary of Contents for Vacmaster VJH1245PF
- Page 1 45L 1200W VJH1245PF Original Instructions...
-
Page 4: Table Of Contents
Maintenance…………..………....................Troubleshooting…………..………....................Technical Data…………..………....................Recycling and Disposal…………..………................... ® Thank you for purchasing this Vacmaster wet and dry vacuum cleaner. Feel confident that with ® Vacmaster you are obtaining a high-quality product that is engineered for optimal performance. This vacuum cleaner is suitable for use with both liquids and dry materials. -
Page 5: Safety Information
SAFETY INFORMATION READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER. This machine is intended for commercial use, for example in hotels, schools, hospitals, factories, shops, offices and rental businesses. Any other use is considered as improper use. The manufacturer accepts no liability for any damage resulting from improper use. - Page 6 • Clear the working area of any items or possessions that you do not wish to be vacuumed before operation. • Keep cord away from heated surfaces. • Do not expose to rain. Store indoors. • Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord.
- Page 7 • For additional protection: It is recommended that this vacuum cleaner can be used in conjunction with residual current device (RCD) with a rated residual current of 30mA or less. • If foam or liquid escapes from the machine, switch off immediately.
-
Page 8: Unpacking And Checking Carton Contents
Cross section Cable length < 16 A < 25 A up to 20 m 1.5 mm 2.5 mm 20 to 50 m 2.5 mm 4.0 mm WARNING: When carrying out service or repair operations, all contaminated items which cannot be satisfactorily cleaned are to be disposed of;... -
Page 9: Assembly
ASSEMBLY NOTE: A Phillips screwdriver is required. 1. Remove all the contents from inside of the vacuum cleaner container. 2. Turn the container upside down and insert the feet with casters into the slots and apply pressure until they click into place. Secure them with supplied screws (Fig. 1). 3. - Page 10 For Dry Vacuuming: WARNING: BEFORE INSTALLING, REMOVING OR CLEANING THE VACUUM CLEANER FILTER, ENSURE THAT THE POWER CORD IS UNPLUGGED AND SWITCHED OFF. 1) To prepare your vacuum cleaner for dry vacuuming, install the cartridge filter over the filter cage with the flat end of the filter towards the vacuum power head.
-
Page 11: Maintenance
MAINTENANCE WARNING: REMOVE THE POWER CORD FROM THE POWER SUPPLY BEFORE CARRYING OUT ANY MAINTENANCE. 1) Keep all safety devices, air vents and the motor housing free of dirt and dust. Use a soft, dry brush to clean the equipment regularly. 2) Clear all dirt or debris from the collection tank after each use. -
Page 12: Troubleshooting
TROUBLESHOOTING. Cleaning Performance Vacmaster vacuum cleaners are tested for endurance. If your motor is operating, then the most likely cause for a loss in suction is a blockage or an opening in the vacuum. To maintain a high cleaning performance from your machine, it is important to replace or clean cartridge filters as necessary. -
Page 13: Technical Data
TECHNICAL DATA Model Number VJH1245PF Motor 220-240V~50Hz Power Input 1200W Tank Volume Net Weight 9.2kg Max. Vacuum Pressure 17kPa / 170hPa Max. Flow Rate 41L/s / 147.6m³/h Sound Pressure Level (L 78dB(A) K=2dB Vibration <2.5m/s K=1.5m/s RECYCLING AND DISPOSAL This marking indicates that this product should not be disposed with other household wastes. - Page 14 ①...
- Page 16 VJH1245PF 12, SHALIN BUNGLOWS, B/H KARMAJYOT BUNGLOWS, NR.S.P RING ROAD, SHILAJ, AHMEDABAD, GUJARAT, 380058...
