Refer to Lubrication
Lubricate the grease nipple on the pivot axle
A
with a grease gun.
Lubricate the grease nipple on the wheel
B
axle with a grease gun.
Lubricate the grease nipple with a grease
C
gun.
Always use good quality grease. Always use
recommended oil, refer to
28 .
To lubricate the front wheels
Note:
Use a grease gun when you lubricate the
front wheels.
• Lubricate each set of front wheel mounts (A) and
bearings (B) 3-4 strokes.
A
Troubleshooting schedule
If you cannot find a solution to your problems in this
operator's manual, speak to your Husqvarna service
agent.
24
Technical data on page
B

Troubleshooting

Interval
Each
Mont Year-
25
hly ly
hours
X
X
X
To lubricate the cutting deck
spindles
1. Set the cutting deck in mow position.
2. Lubricate each cutting deck spindle 2-3 strokes.
Note:
Use a grease gun with a rubber hose
when you lubricate the cutting deck spindles.
Each Each Each
50 100 400
hours hours hours
