Siemens CXE200 Quick Start Manual

Plug and play automation edge controller
Hide thumbs

Advertisement

Table of Contents

Plug and play automation
CXE200 Edge controller
A6V13951362_en--_b
2024-04-04
Edge controller for integration with Siemens Plug and play automation HVAC
and building automation and control systems
●
Integration of Modbus (RTU) and M-Bus data points
●
Ethernet ports for WAN and LAN
●
WLAN interface for engineering and commissioning
●
Operating voltage AC 24 V or DC 24 V
●
Mounting on standard rails or on the wall
●
Plug-in screw terminal blocks
●
Remote tool access, update and configuration via Siemens Cloud Services
(depending on firmware)
Smart Infrastructure

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CXE200 and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens CXE200

Summary of Contents for Siemens CXE200

  • Page 1 Plug and play automation CXE200 Edge controller Edge controller for integration with Siemens Plug and play automation HVAC and building automation and control systems ● Integration of Modbus (RTU) and M-Bus data points ● Ethernet ports for WAN and LAN ●...
  • Page 2 Functions CXE200 is a pre-programmed edge controller for controlling building equipment and collecting data. It combines the essential functionality of a gateway with an edge controller. The device integrates thermostats, meters and other devices via plug and play, all managed from the Plug and play automation cloud application.

  • Page 3: Technical And Mechanical Design

    Technical and mechanical design 1 Plastic housing 2 LEDs for communication and status 3 Product identifier DMC 4 Service button 5a Ethernet port for LAN with 2 status LED, used for maintenance and troubleshooting 5b Ethernet port for WAN with 2 status LED, used for the cloud connection 6 Plug-in terminal block with screw terminals KNX PL-Link (for future use)
  • Page 4 LED displays and service button Activity Color Behavior Status Ethernet port Green Steady ON Link active Steady OFF No connection Flashing Network traffic Yellow Steady ON Link 100 Mbps Steady OFF Link 10 Mbps Green Steady ON Device operational Steady OFF Device powered off Flashing Device booting, sysx services not yet running...
  • Page 5 Delete all personal data and dispose of the item(s) at separate collection and recycling facilities in accordance with local and national legislation. For additional details, refer to Siemens information on disposal. Smart Infrastructure A6V13951362_en--_b 2024-04-04...

  • Page 6: Warranty

    Warranty The application-specific technical data is guaranteed only in combination with the Siemens products listed in the 'Device combinations' section. If third-party products are used, any guarantee provided by Siemens will be invalidated. Technical data Power supply Operating voltage AC 24 V (24 V≃, ⏊, AC 24 V -15 / +20 % (PELV)
  • Page 7 Ethernet interface Interface type 10Base-T / 100Base-TX, IEEE 802.3 compatible Bit rate 10/100 Mbps, autosensing Protocol BACnet on UDP/IP and HTTPS on TCP/IP Cabling (in-house cabling only), cable 10 Mbps: Min. CAT3, shielded cable is recommended type 100 Mbps: Min. CAT5, shielded cable is recommended Cable length Max.
  • Page 8 M-Bus interface Interface type M-Bus according to EN 13757-2, galvanically isolated Baud rate 300, 600, 1200, 2400, 4800, 9600 (depending on the configuration) Cabling (in-house cabling only) 2-wire cable, 0.8 mm / AWG20 Cable length Max. 100 m (330 ft) Bus power Min. 24 V Max.

  • Page 9: European Union Conformity

    (RoHS compliance, materials composition, packaging, environmental benefit, disposal). Documents can be downloaded at http://siemens.com/bt/download. European Union conformity Contact for regulatory topics: (EU) Siemens AG, Berliner Ring 23, DE-76437 Rastatt Housing Color top/bottom 2003 Ti-Grey / 804 Black Dimensions per DIN 43880, see dimensions Weight without/with packaging 351 g / 391 g...

  • Page 10: Connection Terminals

    Connection terminals 5 6 7 10 11 AC/DC 24V 71 72 65 66 67 68 69 70 Terminal Symbol Description 1, 2 2 x RJ45 interface for Ethernet 3, 4 KNX interface (for future use) 5, 6 ~ , ⏊ Operating voltage AC 24 V or DC 24 V Functional ground must be connected on the installation side with the building grounding system (PE).
  • Page 11 Dimensions All dimensions in mm and inches 4 (0.16") 26.5 (1.04") 45 (1.77") 49 (1.91") 129 (5.08") 65.5 (2.58") 144 (5.67") 70.5 (2.78") Smart Infrastructure A6V13951362_en--_b 2024-04-04...
  • Page 12 Issued by © Siemens 2024 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V13951362_en--_b Edition 2024-04-04...
