- Page 1 SDN PowerConnect™ Rack-Mount Panel Instructions Item #: 1871027 (Single Kit) • Item #: 1871312 (Dual Kit)
- Page 2 I. General • Indoor use only • Dimensions: 1.71 in. H x 8.56 in. W x 12.29 in. D (4.34 cm H x 21.74 cm W x 31.22 cm D) • Uses RJ45 connectors • Ambient operating temperature • II. Connections & Indicators Front view Back view LED Indicators...
- Page 3 III. Mounting Instructions Single Kit Note: A single panel can be installed in a 1U rack on either the left or right side as needed for the application. 1. Right Side Mount (Figure 1a) • Mount the “short bracket” to the right side of the enclosure using the 4 flat-head screws.
- Page 4 IV. Motor and Device Compatibility Compatible with Somfy’s line of 24V DC tubular motors: • SDN (Somfy Digital Network™) – Integrated RS485 SDN Motor cable available: • Non-plenum #9020126 (US), #9020452 (CA) • Plenum #9020127 (US), #9020453 (CA) V. Troubleshooting...
