ASROCK G43TWINS-FULLHD Brochure & Specs

G43Twins-FullHD
Intel ® G43 + ICH10 Chipsets
Product Brief
- LGA 775 for Intel ® Core TM
Core TM 2 Duo / Pentium ®
Celeron ® , supporting Penryn Quad Core Yorkfield
Dual Core Wolfdale processors
- Solid Capacitor for CPU power
- Supports FSB 1333/1066/800MHz CPUs
- Supports Dual Channel
with max. capacity up to 4GB and Dual Channel DDR2
1066/800/667 (2 x DIMM slots) with max. capacity up to
8GB
- Intel ® Graphics Media Accelerator
4.0, DirectX 10, Max. shared memory
- 1 x PCI Express 2.0 x16 slot (green @ x16 mode)
- 6 x SATAII 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug functions
- PCIE Gigabit LAN 10/100/1000 Mb/s
- Three VGA Output options: D-Sub,
Port with ASRock DVI_DisplayPort Card
- Supports HDCP function
Card
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with ASRock DVI_DisplayPort Card
- 7.1 CH Windows ® Vista™ Premium Level HD Audio
(ALC888 Audio Codec)
- 1 x WiFi/E header
- Supports I. O. T. (Intelligent Overclocking Technology),
ASRock OC Tuner
- Supports Smart BIOS
- Windows ® Vista TM Premium 2008 Logo Ready
- Free Bundle: 1 x ASRock DVI_DisplayPort Card
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
2 Extreme / Core TM 2 Quad /
Dual Core / Celeron ® Dual Core /
DDR3 1066/800 (2 x DIMM slots)
X4500,Pixel Shader
352MB
DVI-D and Display
with ASRock DVI_DisplayPort
Detail Specification
Platform - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x
- Solid Capacitor for CPU power
CPU
- LGA 775 for Intel
/ Celeron
- Supports FSB1333/1066/800 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
Chipset - Northbridge: Intel
- Southbridge: Intel
- Dual Channel DDR3/DDR2 memory technology
Memory
- 2 x DDR3 DIMM slots
- Supports DDR3 1066/800 non-ECC, un-buffered
- Max. capacity: 4GB
- 2 x DDR2 DIMM slots
- Supports DDR2 1066/800/667 non-ECC, un-buffered
- Max. capacity: 8GB
- 1 x PCI Express 2.0 x16 slot (green @ x16 mode)
Expansion Slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
- Intel
Graphics
- Pixel Shader 4.0, DirectX 10
- Max. shared memory 352MB
- Three VGA Output options: D-Sub, DVI-D and
- Supports DVI-D and DisplayPort with ASRock DVI_
- Supports HDCP function with ASRock DVI_DisplayPort
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
Audio - 7.1 CH Windows
LAN
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111B/RTL8111C
- Supports Wake-On-LAN
Rear Panel I/O
ASRock GLAN_8CH I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA Port
- 6 x Ready-to-Use USB 2.0 Ports
and
- 1 x RJ-45 LAN Port
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Connector
- 6 x SATAII 3.0 Gb/s connectors, support NCQ, AHCI and
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 1 x WiFi/E header
BIOS Feature
- 8Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, DRAM, NB, SB,VTT Voltage Multi-adjustment
- Supports I. O. T. (Intelligent Overclocking Technology)
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
Unique Feature - ASRock OC Tuner
- Hybrid Booster:
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
- Microsoft
Certifications
- FCC, CE, WHQL
Accessories - Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 Cables
- 1 x SATA Data Cable (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
- 1 x ASRock DVI_DisplayPort Card (Optional)
www.as rock.com
24.4 cm
® Core TM 2 Extreme / Core
Core TM 2 Duo / Pentium ® Dual Core / Celeron
® ,supporting Penryn Quad Core Yorkfield and
Dual Core Wolfdale processors
® G43
® ICH10
memory
memory
® Graphics Media Accelerator X4500
DisplayPort with ASRock DVI_DisplayPort Card
DisplayPort Card
Card
with ASRock DVI_DisplayPort Card
® Vista™ Premium Level HD Audio
(ALC888 Audio Codec)
Bass / Line in / Front Speaker / Microphone
Hot Plug functions
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
® Windows ® 2000 / XP / XP 64-bit / Vista
Vista TM 64-bit compliant
TM 2 Quad /
® Dual Core
TM /
