ASROCK G31DE Specifications

G31DE
Intel ® G31 + ICH7 Chipsets
Product Brief
- Compatible with all FSB1600 MHz CPU
®
- Intel Graphics Media Accelerator 3100,
DirectX 9.0, Max. shared memory 384MB
- PCIE Gigabit LAN
- Supports ASRock Instant Boot
- Supports Smart BIOS, ASRock OC Tuner,
Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
www.as rock.com

Detail Specification

- ATX Form Factor: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm
Platform
CPU - LGA 775 for Intel
TM
Core 2 Duo / Pentium
®
/ Celeron , supporting Penryn Quad Core Yorkfield and
Dual Core Wolfdale processors
- Compatible with all FSB1600/1333/1066/800MHz CPUs
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
Chipset - Northbridge: Intel
- Southbridge: Intel
- Dual Channel DDR2 memory technology
Memory
- 2 x DDR2 DIMM slots
- Supports DDR2 1066/800/667 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
Expansion Slot
- 2 x PCI Express x1 slots
- 3 x PCI slots
Graphics
®
- Intel Graphics Media Accelerator 3100
- Pixel Shader 2.0, DirectX 9.0
- Max. shared memory 384MB
- 5.1 CH Windows
Audio
(Realtek ALC662 Audio Codec)
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
LAN
- Realtek RTL8111DL
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector - 4 x SATAII 3.0 Gb/s connectors
(No support for RAID and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Print port header
- 1 x HDMI_SPDIF header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature - 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM Voltage Multi-adjustment
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS ®
- Microsoft Windows
TM
Vista 64-bit compliant
Certifications - FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 100 Cable
- 1 x SATA Data Cable (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
® Core TM 2 Extreme / Core TM 2 Quad /
® ®
Dual Core / Celeron Dual Core
®
G31
®
ICH7
® Vista TM Premium Level HD Audio
® TM
2000 / XP / XP 64-bit / Vista /
