Summary of Contents for ADDAC System ADDAC200CT
- Page 2 ADDAC200CT Assembly Guide May.2024 ADDAC SYSTEM page 2...
- Page 3 ADDAC200CT Assembly Guide STEP 1: First let’s place and solder all sockets. Notice the orientation of the indents. ADDAC SYSTEM page 3...
- Page 4 ADDAC200CT Assembly Guide STEP 2: Locate the 3.5mm jacks and cut the thinest leg like shown below. STEP 3: Proceed by placing and solder the jacks to the pcb. ADDAC SYSTEM page 4...
- Page 5 ADDAC200CT Assembly Guide STEP 4: Next place and solder all leds, follow our color pattern below. Pay close attention to the led polarites, notice the + on the pcb. ADDAC SYSTEM page 5...
- Page 6 ADDAC200CT Assembly Guide STEP 5: Place all spacers at the four corners and attach both pcbs together ADDAC SYSTEM page 6...
- Page 7 ADDAC200CT Assembly Guide STEP 6: Finish by placing the four rubber feet. ADDAC SYSTEM page 7...
- Page 8 ADDAC200CT Assembly Guide Congratulations you’re done! Happy Patching!! ADDAC SYSTEM page 8...
-
Page 9: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC200CT ASSEMBLY GUIDE Revision.01 May.2024...
