Asus A620M-AYW WIFI Manual page 25

7. Install your M.2 module to the M.2 slot.
Ensure that there is nothing obstructing your M.2 module when installing the M.2 module
to the M.2 slot.
8. Rotate the M.2 Q-Latch clockwise to secure the M.2 module in place.
9. Remove the plastic film from the thermal pads on the bottom of the heatsink.
If the thermal pad on the M.2 heatsink becomes damaged, we recommend replacing it
with the bundled thermal pad or a thermal pad with a thickness of 1.25mm.
10. Replace the heatsink.
11. Secure the heatsink using the screws on the heatsink.
11
Motherboard User Manual
11
10
1-13
