- Page 1 Mobile Monocular Passenger Counting Camera Quick Start Guide V1.0.0...
-
Page 2: Foreword
Foreword Safety Instructions The following signal words might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury. Indicates a potential risk which, if not avoided, could result in property damage, data loss, lower performance, or unpredictable result. -
Page 3: Important Safeguards And Warnings
Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Transportation Requirements Transport the device under allowed humidity and temperature conditions. ... - Page 4 Ground the earthing portion of the device to improve its reliability. Ground the function earthing portion of the device to improve its reliability (certain models are not equipped with earthing holes). The device is a class I electrical appliance. Make sure that the power supply of the device is connected to a power socket with protective earthing.
- Page 5 Clean the device body with a soft dry cloth. If there are any stubborn stains, clean them away with a soft cloth dipped in a neutral detergent, and then wipe the surface dry. Do not use volatile solvents such as ethyl alcohol, benzene, diluent, or abrasive detergents on the device to avoid damaging the coating and degrading the performance of the device.
-
Page 6: Table Of Contents
Contents Foreword ................................II Important Safeguards and Warnings ......................III 1 Structure ................................ 7 Unpack and Check ..................................7 Appearance ....................................7 Dimension ..................................... 8 Port Definition ..................................... 8 2 Installation ..............................10 3 Network configuration ..........................14 Initializing Device ..................................14 Modifying Device IP Address ............................... -
Page 7: Structure
Structure Unpack and Check The following figures are for reference only, and the actual product shall prevail. For tools or accessories not mentioned in the box, please purchase them as needed. Unpack and Check Appearance Appearance... -
Page 8: Dimension
Table 1-1 Appearance description Name Lens IR Light Fixing Screw Lead Hole TF Card Slot Reset Button Installation Hole Dimension Dimension(mm[inch]) Port Definition When connecting cables, it is recommended to use insulating tape and waterproof tape to avoid short circuit and water leakage. Ports... - Page 9 Table 1-2 Functions Cable Name Description Ethernet and power Aviation port Used for connecting to mobile video recorder. supply port Ethernet port Connect to standard Ethernet cable. POWER Power input port Inputs 12V DC power.
-
Page 10: Installation
Installation The installation surface is required to sustain at least 3 times the total weight of the bracket and the device. Before fixing the cover, please check whether the waterproof rubber ring is loose; After fixing the cover, tighten the fastening screws so as not to affect the waterproof performance of the device. - Page 11 Concealed Installation (The following steps take exposed installation as example.) Screw in 4 ST4×30 self-tapping screws on the bracket with a cross screwdriver to fix the camera on the installation surface. Self-tapping screws (Optional.) Insert the TF card according to the direction shown by the arrow. Cut off the power supply before installing TF card.
- Page 12 Insert the TF card Connect the cable to mobile video recorder and log in to the WEB interface (refer to "3.3Logging in to WEB Interface" for details.), preview the video image in real time and adjust the camera lens according to the image. Mobile video recorder from different manufacturers vary and the actual product shall prevail.
- Page 13 Install the camera cover Installation completed...
-
Page 14: Network Configuration
Network configuration Device initialization and IP setting can be finished with the "ConfigTool" or in WEB interface. For more information, see the WEB operation manual. Device initialization is available on select models, and it is required at first use and after device is ... - Page 15 Setting Enter the Start IP and End IP of the network segment in which you want to search devices, and then click OK. All the devices found in the network segment are listed. Select one or several devices whose Status is Uninitialized, and then click Initialize. The Device initialization interface is displayed.
-
Page 16: Modifying Device Ip Address
The device status in the Modify IP interface (Figure 3-1) turns to Initialized. Modifying Device IP Address You can modify IP address of one or multiple devices in one time. This section is based on modifying IP addresses in batch. Modifying IP addresses in batch is available only when the corresponding devices have the ... - Page 17 If you forget your password, click Forgot password? to reset it. Login Enter user name and password in the log in box, and then click Login. For first time login, click Click here to download and install the plugin as instructed. WEB interface...
-
Page 18: Cybersecurity Recommendations
Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. - Page 19 Enable HTTPS We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel. MAC Address Binding We recommend you to bind the IP and MAC address of the gateway to the device, thus reducing the risk of ARP spoofing.
