PRODUCT INSTRUCTIONS
The Hydrant Buddy Kit Includes:
• Hydrant Buddy Tool
• Batteries (2)
• Charger
• Socket
• Hex Key
Read these instructions thoroughly before using the Hydrant Buddy. For more in-
formation, call HydroVerge at (952) 484-8610 or email info@HydroVerge.com. This
product is sold with the understanding that the purchaser agrees to thoroughly
train all operators and maintenance personnel in the correct and safe assembly,
operation, and maintenance of the product and to provide adequate supervision of
personnel at all times. Retain these instructions for future reference. If this product
is resold or otherwise conveyed, purchaser must pass on the instructions to the
new user.
• Wrench
• Grease Zerk
• Product Instructions
• Aluminum Crate
Advertisement
Table of Contents
Related Manuals for HydroVerge Hydrant Buddy
Summary of Contents for HydroVerge Hydrant Buddy
- Page 1 • Aluminum Crate • Hex Key Read these instructions thoroughly before using the Hydrant Buddy. For more in- formation, call HydroVerge at (952) 484-8610 or email info@HydroVerge.com. This product is sold with the understanding that the purchaser agrees to thoroughly...
-
Page 2: Table Of Contents
Table of Contents Section 1: Safety .................3 Section 2: Product Specifications ..........4 Section 3: Components ..............5 Section 4: Hydrant Buddy Controls ..........6 Section 5: Operation ..............7 Set up and Operation - Hydrants ..........8 Reverse Direction ..............9 Section 6: Other Attachments ...........10 Attachment Options ..............10... -
Page 3: Section 1: Safety
THE OPERATOR DURING USE. Misuse could lead to loss of operator balance and potential fall injury. The Hydrant Buddy is designed to produce an intense amount of torque. PLEASE USE EXTREME CAUTION AT ALL TIMES. This tool has been designed to help operators open and close valves. -
Page 4: Section 2: Product Specifications
Section 2: Product Specifications Model Name Hydrant Buddy Model Type Cordless Width (in) 6.5” Length (in) 26” Height (in) 12” from output drive to top motor handle Weight 22.5 lbs with socket and battery Battery Capacity Up to 20 hydrants / 10 gate valves... -
Page 5: Section 3: Components
• Magnets (3) • Socket • Manual Read these instructions thoroughly before using the Hydrant Buddy. For more in- formation, call HydroVerge at (952) 484-8610 or email Jeff@HydroVerge.com. This product is sold with the understanding that the purchaser agrees to thoroughly... -
Page 6: Section 4: Hydrant Buddy Controls
Section 4: Hydrant Buddy Controls Directional Switch Trigger Handle Lock Battery Digital Counter ROTATION FORCE AWAY FROM OPERATOR Counter Sensor Reaction Set Screw Handle Threaded Fastener Socket HV-0104 March 2024... -
Page 7: Section 5: Operation
ONLY USE MOTOR POWER TO ACTUATE THE VALVE, OTHERWISE, DAMAGE TO THE MOTOR MAY OCCUR. Follow all Hydrant Buddy procedures outlined in these Product Instructions. Failure to follow product usage instructions, including manually turning the valve, will invalidate the product warranty. -
Page 8: Set Up And Operation - Hydrants
1. Insert the socket onto the Hydrant Buddy 3/4” square drive shaft. 2. Tighten the set screw to secure the socket. 3. Place the Hydrant Buddy with the socket onto the hydrant with the reaction handle facing away from the operator. -
Page 9: Reverse Direction
Reverse Direction 1. Move the handle lock to the “unlocked” position and swing the reac- tion handle to the opposite side of the Hydrant Buddy. UNLOCKED LOCKED Handle Lock 2. Now, move the handle to the “locked” position. This sets the reaction handle again pulling away from the operator. -
Page 10: Section 6: Other Attachments
Section 6: Other Attachments Attachment Options ROTATION FORCE AWAY FROM OPERATOR GVK-E GVK-L GVK-S HBS-5A HBS-3A HBS-114 HBS-1M Valve Key Extension 78"-135" 48"-82" Adjustable Adjustable 1-1/4" 3/4” Female to 36" Depth Capacity Depth Capacity 5-point Socket 3-point Socket 4-point Socket 1”... -
Page 11: Gate Valve Key
Gate Valve Key The gate valve key can be purchased separately. It fits onto a 2” square operating nut attaching directly to the Hydrant Buddy to exercise gate valves. March 2024 HV-104... - Page 12 2. Adjust the length of the key to ensure the top of the key is at a com- fortable height for the operator. 3. Ensure the Hydrant Buddy tool is fully seated on the gate valve key with the reaction handle facing away from the operator.
- Page 13 Reverse Direction 1. Move the handle lock to the “unlocked” position and swing the reac- tion handle to the opposite side of the Hydrant Buddy. UNLOCKED LOCKED Handle Lock 2. Now, move the handle to the “locked” position. This sets the reaction handle again pulling away from the operator.
-
Page 14: Section 7: Maintenance
Section 7: Maintenance Greasing the Output Drive & Output Drive Housing For proper operation, the Hydrant Buddy should be greased in two locations every 12 months. Greasing the Output Drive 1. Using the included hex key, remove the threaded plug from the output drive. - Page 15 3. Attach a grease pump containing ThermaPlex Hi-load - Item #70414. 4. Pump 1 oz. of grease. 5. Disconnect the grease pump. 6. Rotate the output drive by slowly operating the Hydrant Buddy motor. 7. Repeat steps 3-6 four more times. 8. Remove the grease zerk.
-
Page 16: Reversing The Counter Switch
Reversing the Counter Switch If you typically use the Hydrant Buddy for only gate valves and want to switch the direction of the counter, use the following process: 1. Remove the screw on the counter. 2. Swap the sensor positions. -
Page 17: Section 8: Reference Tables
Section 8: Reference Tables Gate Valve Tables NOTE: The following tables are for reference only. For more accurate information, see the specific hydrant manufacturer to determine the number of valve rotations. Most Double Disk Valves Used in Water Systems Valve Size Number of Turns 3”... - Page 18 Most Metal-Seated Sewage Valves Valve Size Number of Turns 3” 4” 6” 8” 10” 12” 14” 16” 18” 20” HV-0104 March 2024...
-
Page 19: Section 9: Troubleshooting
Please call HydroVerge at 952-484-8610 at any time with questions. We are available and eager to answer your questions about the proper use of the Hydrant Buddy, as well as, solve any problems you may have with the tool. March 2024... - Page 20 For the latest in Hydrant Buddy product news and insights, visit our website at www.HydroVerge.com. For more information, call HydroVerge at (952) 484-8610 or email info@HydroVerge.com. HV-721_HydrantBuddy_Rev 03/24...
