Sealey PT1150SC.V4 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear safety
footwear
instruction
manual
1. SAFETY
DO NOT use a faulty or damaged truck.
8
DO NOT adapt or modify the truck.
8
Before using the truck all parts and working mechanisms should be checked for wear or damage. Pay particular attention to the wheels,
9
handle and fork lifting and lowering mechanism. Any parts found to be worn, damaged or suspect should be repaired or replaced before
the truck is used. All repairs must be carried out by an authorised Sealey service agent.
Personnel who operate the truck and those in the vicinity of operation should wear safety shoes with reinforced toe caps at all times.
9
DO NOT place any part of your body in the lifting mechanism or under the forks or load.
8
DO NOT allow others to ride on the truck.
8
DO NOT lift or move unstable or loosely stacked loads.
8
Take special care when moving long, high or wide loads in order not to dislodge the load by striking any architectural features, permanent
9
fixtures, vehicles or people in the area of operation.
Always ensure that the load is evenly distributed across the forks with the centre of the load being at the halfway point of the length of
9
the forks.
DO NOT overload the truck - refer to the specification for maximum permitted load.
8
If a load is left unattended even for a very short period of time it should be lowered to the ground.
9
When not in use the truck should be left in the lowered position.
9
Ensure that the width and length of the forks is correct for the pallet to be lifted.
9
Ensure that the truck is sufficiently inserted into the pallet to lift the full width and depth of the pallet.
9
DO NOT use truck on sloping or uneven ground and do not attempt to negotiate curbs, steps or ramps. Only use the truck on level, flat,
8
and hard surfaces.
The operator of the truck must be physically capable of controlling the load selected; particularly in relation to stopping a rolling load.
9
DO NOT use the truck in areas of low lighting (minimum 50 lux or less).
8
2. INTRODUCTION
Heavy-duty pallet truck suitable for warehouse and general handling duties. Features built-in weighing scales with an accuracy of +/-1kg.
6-Digit, high contrast LCD display. Control panel has a tare function to allow for packaging weight. Scales powered by a built-in 6V/4.5A
rechargeable battery. Supplied with charging level indicator pin charger. This item is heavy. Extra assistance must be provided at the
delivery point to help its safe delivery.
3. SPECIFICATION
Model No:
Battery:
Capacity:
Display:
Fork Spread:
Forks (Length x Overall Width): 1150 x 555mm
Maximum Height:
Minimum Height:
© Jack Sealey Limited
PALLET TRUCK WITH SCALES - 2000KG CAPACITY
1150 X 555MM
PT1150SC.V4
MODEL NO:
PT1150SC.V4
6V/4.5A Lead Battery
2000kg
6-Digit LCD
115mm
200mm
85mm
Original Language Version
PT1150SC.V4 Issue 3 (4) 21/02/24
