- Page 1 EXS09GH1W, EXS12GH1W EXS18GH1W, EXS22GH1W Split Type Room Air Conditioner...
-
Page 2: Table Of Contents
Table of Contents Congratulations ..............2 Safety Precautions ..............3 Product´s Description ............5 Indoor Unit Display ..............6 Remote Control ..............6 Remote Control Description ..........7 Remote Control Display Indicators ........9 First Use ................10 How to use the Remote Control ...........10 How to use the Indoor Unit ..........15 Emergency Operation ............16 Optimal Operation ............ -
Page 3: Congratulations
Congratulations Congratulations and thank you for choosing Conditions of use Electrolux split-type air conditioner. We are sure This appliance is intended to be used in you will find your new air conditioner a pleasure to household and similar applications such as: use. • Staff kitchen areas in shops, offices and other Before you use the air conditioner, we recommend working environments. -
Page 4: Safety Precautions
Electrolux service agent. If answers to common problems in the chart of this abnormal status continues the air troubleshooting tips on page 20-21. If you review the... - Page 5 Safety precautions Usage caution Exposure to direct airflow from the air conditioner for an extended period of time could Select the most appropriate temperature. be hazardous to your health. It can save electricity. Do not expose people, pets or plants to the Do not keep windows and doors open for direct airflow for an extended period.
-
Page 6: Product´s Description
Product Description Air inlet Indoor Unit Air Outlet Outdoor Unit Air inlet (rear) Mode Light Turbo Healthy Timer-On Temp Timer-Off Clock Swing I feel Air inlet (side) Air Outlet Remote control Front panel Remote control holder Digital display Refrigerant pipe (if applicable) Healthy air filter (behind the dust filter) Drain hose (if applicable) Pre-dust filter Power cable (if applicable) -
Page 7: Indoor Unit Display
Indoor Unit Display • If you keep the remote control in a position that hinders proper signal transmission, a time lag of up to 15 minutes may occur. • When the remote control sends out a signal, the symbol will blink for about 1 second on the Signal display. -
Page 8: Remote Control Description
Remote Control Description Turbo Button Models with Cold-Plasma function Press this button in COOL or HEAT mode to put the fan into the high speed Turbo mode and the air conditoner will work at maximum power. Press again to cancel this function. Healthy Button Press this button to turn the Cold-Plasma function ON or OFF. - Page 9 Remote Control Description Turbo Button Models without Cold-Plasma function Press this button in COOL or HEAT mode to put the fan into the high speed Turbo mode and the air conditoner will work at maximum power. Press again to cancel this function. X-Fan Button Press the X-Fan button to active the Self-Cleaning.
-
Page 10: Remote Control Display Indicators
Remote Control Display Indicator Fan Speed Display Transmission Indicator: Displays the selected fan speed in the following Displays when the remote control transmits sequence: signals to the indoor unit. “ ” (Low), “ ” (Medium), “ ” (High) and Turbo Display Auto. Displays when Turbo function is selected. In Auto speed, only “... -
Page 11: First Use
First Use 1 Ensure the unit is plugged in and power is available. 2 Be sure the batteries are inserted correctly in the remote control (the lights on the remote control will be on). 3 Set the time by Control buttons and confirm by pressing the Clock button. 4 Point the remote control to the indoor unit and press ON/OFF button to turn the unit on. - Page 12 Start 2 Mode Button 1 ON/OFF Button Press to select FAN. Press this button to turn the air conditioner on. 3 Fan Button The temperature indicator on the indoor unit Press to select the desired fan speed at: Auto, display lights on. Low, Medium and High.
- Page 13 3 Control Buttons 3 Point the remote control to the indoor unit, confirm the set time by pressing the Timer-On button. Set the desired temperature. Normally, set between 21ºC to 28ºC. symbol will stay on the remote control’s display. 4 Fan Button Check that the Timer indicator on the display panel of indoor unit is illuminated.
- Page 14 1 Press the Timer-On button. 2 Set the desired time by pressing repeatedly or holding down the Control buttons until 18:00 shows in the display of the remote control. 3 Confirm the set time by pointing the remote control to the indoor unit and pressing again the Timer-On button.
- Page 15 Setting the Clock Economy (Eco) Operation Press Eco button in COOL or HEAT (if applicable) mode, the air conditioner will automatically increase (in COOL mode) or decrease (in HEAT mode) 1 C per hour over a 2 hour period. The set temperature will be steady for the next 5 hours then the unit will stop.
-
Page 16: How To Use The Indoor Unit
• When the louver moves to the desired direction, How to Use the Indoor Unit press the Swing button again and the louver will stay at where it is. Additional Options • Press the Swing button again and the louver will start swing up and down automatically. 1 Smart Restart Function The air conditioner resumes automatically with the previous settings after a possible power... -
Page 17: Emergency Operation
• Press the Manual Control button again to turn the • Do not move the horizontal louver air conditioner off. manually. Always use the Swing button. The operation mode is seen in the following table. Moving the louver manually may cause malfunction during operation. -
Page 18: Cleaning And Maintenance
Cleaning and Maintenance Maintenance The following maintenance operations must be performed regularly. Maintenance Items Recommended frequency operations Dust filter Clean Every month or more often if necessary Healthy air filters Replace/clean Every 3 months or more often if necessary Unit casing Clean Every month or more often if necessary Water tray and Clean and check for Each season before start up*... - Page 19 Dust filter warning Do not touch or try to clean the cold plasma generator (if applicable). It may cause an electric shock. General maintenance Clean the Dust filter with a vacuum cleaner or If the air conditioner is not going to be used for a water, then dry it up in cool place. long period of time: • Operate in FAN only mode for 3~4 hours to allow the unit to completely dry out.
-
Page 20: Operation Tips
environment that has a high relative humidity. Operation Tips • A white mist may generate due to moisture The following events may occur during normal generated from defrosting process when the air operation: conditioner restarts in HEAT mode operation after defrosting. 1. Protection of the air conditioner. -
Page 21: Troubleshooting
Trouble Shooting The air conditioner is not user serviceable. Incorrect repair may cause electric shock or fire. Please contact an authorised service center for professional repair. warning If one of the following situations occur, immediately stop the air conditioner, disconnect the power, and contact the authorised service center. • If error code appear on the display window of • Water or other liquid is splashed into the unit. - Page 22 The following checks prior to contact may save you time and money. Malfunctions Cause Malfunctions Cause The unit does not operate if it is • The humidity is high. The unit does turned on immediately after it is Water leakage • Condensing water overflows. not operate turned off.
