NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
OPERATING­INSTRUCTIONS­AND­OWNER'S­MANUAL
READ INSTRUCTIONS CAREFULLY:­Read­and­follow­all­instructions.­Place­instructions­in­a­safe­
place­for­future­reference.­Do­not­allow­anyone­who­has­not­read­these­instructions­to­assemble,­
light,­adjust­or­operate­the­heater.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
­ — ­ Do­not­store­or­use­gasoline­or­other­flammable­vapors­and­liquids­in­the­vicinity­of­this­or­any­
other­appliance.
—­ Service­must­be­performed­by­a­qualified­service­agency.
This­is­an­unvented­portable­heater.­It­uses­air­(oxygen)­from­the­area­in­which­it­is­used.­Adequate­
combustion­and­ventilation­air­must­be­provided.­Refer­to­page­3.
KEROSENE FORCED-AIR HEATER
www.mrheater.com
800-25 1-0001
•
Model­#
MH50KR, MH80KTR,
MH140KTR, MH185KTR,
MH210KTR
