Sennheiser SET 820 S RF Technical Data

Set 820 S RF
Audiology |
Description
RF stereo receiver for use with the TR 820 RF stereo transmitter or an
RF audio transmission system. The RR 820 S features an audio output
for connecting a pair of headphones, an induction neck loop, induction
couplers or a hearing aid with audio input. The receiver features a large,
easy-to-use volume control and an integrated clip for attaching it to the
clothing.
Features
Individually adjustable to the listener's hearing
j
Large, ergonomic volume control
j
Integrated attachment clip
j
3.5 mm Ø stereo jack socket for connecting headphones,
j
induction accessories or hearing aids with audio input
Automatic transmitter search tuning
j
Delivery includes: 1 RR 820 S stethoset receiver
j
1 BA 151 accupack
Recommended Accessories
BA 151 Spare accupack
j
L 151-2 Charger
j
TR 820 (European version) Transmitter
j
TR 820-UK (UK version)
j
MKE 800 TV, TV microphone
j
HD 25 SP-1 Dynamic headphones
j
EZI 120 Induction coupler
j
EZT 1011 Induction neck loop
j
Product Variants
Set 820 S-UK as Set 820 S, but with UK plug-in
j
mains unit and MKE 800 TV microphone
Wireless Radio Frequency Receiver
for TV Sound Transmission
Technical Data System
Colour ......................................................................... blue/anthracite
Modulation.......................................................................... FM, stereo
Receiving frequencies.................................. 863.25 – 863.75 MHz
Frequency selection .................................frequency search tuning
AF frequency response............................................ 40 Hz – 15 kHz
THD ................................................................................................< 2 %
Signal-to-noise ratio ...........................................................60 dBA
Max. output level................................................. > 700 mV at 32 Ω
AF output ............................................................ 3.5 mm stereo jack
Operating time .............................................................................> 5 h
Power supply ................................................................... 2.4 V DC via
Weight (w/o accupack)...............................................................35 g
Dimensions ............................................................. 95 x 63 x 35 mm
Cat. No. 004146
Cat. No. 004457
Cat. No. 004984
Cat. No. 004992
Cat. No. 004995
Cat. No. 004173
Cat. No. 003448
Cat. No. 001954
Cat. No. 009374
Cat. No. 009373
rms
socket
BA 151 accupack
