1.4

System memory

This motherboard comes with two Double Data Rate 4 (DDR4) Small Outline Dual Inline
Memory Modules (SO-DIMM) sockets. The figure illustrates the location of the DDR4 SO-
DIMM sockets:
DIMM_B1
DIMM_A1
• You may install varying memory sizes in Channel A and Channel B. The system
maps the total size of the lower-sized channel for the dual-channel configuration. Any
excess memory from the higher-sized channel is then mapped for single-channel
operation.
• Always install DIMMs with the same CAS latency. For optimal compatibility, we
recommend that you install memory modules of the same version or date code (D/C)
from the same vendor. Check with the retailer to get the correct memory modules.
• The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value.
• For system stability, use a more efficient memory cooling system to support a full
memory load.
• Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and data rate
support depends on the CPU types.
Installing a DIMM
To install a DIMM
PRIME H610T2-CSM D4
Channel
Channel A
Channel B
To remove a DIMM
Sockets
DIMM_A1
DIMM_B1
3
3
1-11
